NCP100/D Datasheet

  • NCP100/D

  • Sub 1V Precision Adjustable Shunt Regulator

  • 8頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

NCP100
Advance Information
Sub 1V Precision Adjustable
Shunt Regulator
The NCP100 is a programmable shunt regulator that provides
accurate referencing for voltage levels of 1 volt and below. This device
is targeted at low voltage applications where a 1.25 volt bandgap
reference is not suitable. This device exhibits wide operating currents
of 0.1 to 20 mA and has sufficient current for driving opto鈥揷ouplers.
Additional applications include feedback isolation for secondary side
regulation of power supplies.
Features:
http://onsemi.com
5
1
TSOP鈥?
SN SUFFIX
CASE 483
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Programmable Output Voltage Range of 0.9 to 6.0 V @ 25擄C
Internal Voltage Reference with Tolerance of
鹵1%
Low Dynamic Output Impedance, 0.2
W
typical
Sink Current Capability of 0.10 mA to 20 mA 鈥?Drives Optos
Directly
鈥?/div>
Equivalent Full鈥揜ange Temperature Coefficient of < 50 ppm/擄C
鈥?/div>
Operating Temperature Range of 鈥?0擄C to 85擄C
鈥?/div>
Micro Miniature TSOP鈥? Packaging 鈥?Same pinout as TLV431
but operates at lower voltage.
Applications:
PIN CONNECTIONS AND
MARKING DIAGRAM
NC
Anode
Cathode
1
RAByw
4
Ref
2
3
5
Anode
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Laptop Computers
Hand鈥揌eld Instrumentation
Cellular Phones
Camcorders and Cameras
Secondary Regulation of Power Supplies
Reliable Reference for single cell Alkaline, NiCD and NiMH
Battery Applications
鈥?/div>
Power Supplies
鈥?/div>
Telecom/Networking
鈥?/div>
Wireless/Portable Electronics
yw = Date Code
(Top View)
ORDERING INFORMATION
Device
NCP100SNT1
Package
TSOP鈥?
Shipping
3000 Units / 7鈥?Reel
Cathode (K)
Reference
(R)
Anode (A)
Figure 1. Representative Block Diagram
This document contains information on a new product. Specifications and information
herein are subject to change without notice.
漏
Semiconductor Components Industries, LLC, 2001
1
February, 2001 鈥?Rev. 2
Publication Order Number:
NCP100/D
