NC7WZU04 TinyLogic錚?UHS Dual Unbuffered Inverter
March 1999
Revised May 2003
NC7WZU04
TinyLogic
錚?/div>
UHS Dual Unbuffered Inverter
General Description
The NC7WZU04 is a dual unbuffered inverter from
Fairchild鈥檚 Ultra High Speed Series of TinyLogic
錚?/div>
in the
space saving SC70 6-lead package. The special purpose
unbuffered circuit design is intended for crystal oscillator or
analog applications. The device is fabricated with
advanced CMOS technology to achieve ultra high speed
with high output drive while maintaining low static power
dissipation over a very broad V
CC
operating range. The
device is specified to operate over the 1.65V to 5.5V V
CC
range. The inputs are high impedance when V
CC
is 0V.
Inputs tolerate voltages up to 7V independent of V
CC
oper-
ating voltage.
Features
s
Space saving SC70 6-lead package
s
Ultra small MicroPak
錚?/div>
leadless package
s
Unbuffered for crystal oscillator and analog applications
s
Balanced Output Drive:
鹵
8 mA at 4.5V V
CC
s
Broad V
CC
Operating Range: 1.65V to 5.5V
s
Low Quiescent Power: I
CC
<
1
碌
A at 5V V
CC
, T
A
=
25
擄
C
Ordering Code:
Order
Number
NC7WZU04P6X
NC7WZU04L6X
Package
Number
MAA06A
MAC06A
Product Code
Top Mark
ZU4
B5
Package Description
6-Lead SC70, EIAJ SC88, 1.25mm Wide
6-Lead MicroPak, 1.0mm Wide
Supplied As
3k Units on Tape and Reel
5k Units on Tape and Reel
Logic Symbol
IEEE/IEC
Connection Diagrams
Pin Assignments for SC70
Pin Descriptions
Pin Names
A
1
, A
2
Y
1
, Y
2
Description
Data Inputs
Output
(Top View)
Pin One Orientation Diagram
Function Table
Y
=
A
Input
A
L
H
H
=
HIGH Logic Level
L
=
LOW Logic Level
AAA represents Product Code Top Mark - see ordering code
Note:
Orientation of Top Mark determines Pin One location. Read the Top
Product Code Mark left to right, Pin One is the lower left pin (see diagram).
Output
Y
H
L
Pad Assignments for MicroPak
TinyLogic錚?is a registered trademark of Fairchild Semiconductor Corporation.
MicroPak錚?is a trademark of Fairchild Semiconductor Corporation.
漏 2003 Fairchild Semiconductor Corporation
DS500220
www.fairchildsemi.com

NC7WZU04P6X 產品屬性

  • 3,000

  • 集成電路 (IC)

  • 邏輯 - 柵極和逆變器

  • 7WZU

  • 反相器

  • 2

  • 1

  • -

  • 1.8 V ~ 5.5 V

  • 1µA

  • 8mA，8mA

  • -

  • -

  • 5.6ns @ 5V，50pF

  • -40°C ~ 85°C

  • 表面貼裝

  • SC-70-6

  • 6-TSSOP，SC-88，SOT-363

  • 帶卷 (TR)

  • NC7WZU04P6XTR
