NBT-168
4
Typical Applications
鈥?Active Amplifier in VCO Circuit
鈥?Buffer Amplifier
鈥?Gain Stage
MICROWAVE GaInP/GaAs DISCRETE HBT
DC TO 12GHz
4
Product Description
The NBT-168 discrete HBT is ideal for low-cost amplifier
and oscillator applications up to 12GHz. Low noise figure,
high gain, high current capability, and medium output give
this device high dynamic range and excellent linearity for
cascaded amplifier designs. This device is also ideally
suited for VCO/buffer amplifier applications. The NBT-168
is packaged in a low-cost, surface-mount ceramic pack-
age, providing ease of assembly for high-volume tape-
and-reel requirements. It is available in either packaged
or chip (NBT-168-D) form, where its gold metallization is
ideal for hybrid circuit designs.
2.94 min
3.28 max
Pin 1
Indicator
1.00 min
1.50 max
0.025 min
0.125 max
Pin 1
Indicator
RF OUT
Ground
RF OUT
0.50 nom
0.50 nom
HT
Lid ID
1.70 min
1.91 max
2.39 min
2.59 max
0.38 nom
Ground
0.98 min
1.02 max
0.37 min
0.63 max
All Dimensions in Millimeters
Notes:
1. Solder pads are coplanar to within 鹵0.025 mm.
2. Lid will be centered relative to frontside metallization with a tolerance of 鹵0.13 mm.
3. Mark to include two characters and dot to reference pin 1.
Optimum Technology Matching廬 Applied
Si BJT
GaAs HBT
SiGe HBT
GaN HEMT
GaAs MESFET
Si CMOS
SiGe Bi-CMOS
Package Style: MPGA, Bowtie, 3x3, Ceramic
!
Si Bi-CMOS
GaInP/HBT
Features
鈥?Reliable, Low-Cost HBT Design
鈥?26.0dB Gain@1.0GHz
鈥?Positive Power Supply Operation
Pin 1
Indicator
1
RF OUT
8
Ground
7
6
5
9
4
RF IN
2
3
Ground
鈥?4-Finger Device for High-Current
Capability
鈥?Low Noise Figure, 1.7dB@2.0GHz
Ordering Information
NBT-168
Microwave GaInP/GaAs Discrete HBT DC to 12GHz
NBT-168-T1 or -T3 Tape & Reel, 1000 or 3000 Pieces (respectively)
NBT-168-D
NBT-168 Chip Form
NBT-168-E
Fully Assembled Evaluation Board
