NBSG16VS
2.5V/3.3V SiGe Differential
Receiver/Driver with
Variable Output Swing
The NBSG16VS is a differential receiver/driver targeted for high
frequency applications that require variable output swing. The device
is functionally equivalent to the EP16VS device with much higher
bandwidth and lower EMI capabilities. This device may be used for
applications driving VCSEL lasers.
Inputs incorporate internal 50
W
termination resistors and accept
NECL (Negative ECL), PECL (Positive ECL), LVTTL, LVCMOS,
CML, or LVDS. The output amplitude is varied by applying a voltage
to the V
CTRL
input pin. Outputs are variable swing ECL from 100 mV
to 750 mV amplitude, optimized for operation from V
CC
- V
EE
= 3.0
V to 3.465 V.
The V
BB
and V
MM
pins are internally generated voltage supplies
available to this device only. The V
BB
is used as a reference voltage
for single-ended NECL or PECL inputs and the V
MM
pin is used as a
reference voltage for LVCMOS inputs. For single-ended input
operation, the unused complementary differential input is connected to
V
BB
or V
MM
as a switching reference voltage. V
BB
or V
MM
may also
rebias AC coupled inputs. When used, decouple V
BB
and V
MM
via a
0.01
mF
capacitor and limit current sourcing or sinking to 0.5 mA.
When not used, V
BB
and V
MM
outputs should be left open.
http://onsemi.com
MARKING
DIAGRAM*
FCBGA-16
BA SUFFIX
CASE 489
SGS
16
LYW
SG16VS
ALYW
QFN-16
MN SUFFIX
CASE 485G
A = Assembly Location
L = Wafer Lot
Y = Year
W = Work Week
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Maximum Input Clock Frequency up to 12 GHz Typical
Maximum Input Data Rate up to 12 Gb/s Typical
40 ps Typical Rise and Fall Times (V
CTRL
= V
CC
- 1 V)
120 ps Typical Propagation Delay (V
CTRL
= V
CC
- 1 V)
*For additional information, refer to Application Note
AND8002/D
Variable Swing PECL Output with Operating Range: V
CC
= 2.375 V
to 3.465 V with V
EE
= 0 V
鈥?/div>
Variable Swing NECL Output with NECL Inputs with
Operating Range: V
CC
= 0 V with V
EE
= -2.375 V to -3.465 V
鈥?/div>
Output Level (100 mV to 750 mV Peak-to-Peak Output;
V
CC
- V
EE
= 3.0 V to 3.465 V), Differential Output Only
鈥?/div>
50
W
Internal Input Termination Resistors
ORDERING INFORMATION
Device
NBSG16VSBA
NBSG16VSBAR2
Package
4x4 mm
FCBGA-16
4x4 mm
FCBGA-16
3x3 mm
QFN-16
3x3 mm
QFN-16
Shipping
100 Units/Tray
500/Tape & Reel
鈥?/div>
Compatible with Existing 2.5 V/3.3 V EP Devices
鈥?/div>
V
BB
and V
MM
Reference Voltage Output
NBSG16VSMN
123 Units/Rail
NBSG16VSMNR2
3000/Tape & Reel
Board
NBSG16VSBAEVB
Description
NBSG16VSBA
Evaluation Board
漏
Semiconductor Components Industries, LLC, 2003
1
April, 2003 - Rev. 5
Publication Order Number:
NBSG16VS/D
