NBSG16M
2.5V/3.3V SiGe Differential
CML Receiver/Driver
The NBSG16M is a differential current mode logic (CML)
receiver/driver. The device is functionally equivalent to the EP16,
LVEP16, or SG16 devices with CML output structure and lower EMI
capabilities.
Inputs incorporate internal 50
W
termination resistors and accept
NECL (Negative ECL), PECL (Positive ECL), LVTTL, LVCMOS,
CML, or LVDS. The CML output structure contains internal 50
W
source termination resistor to V
CC
. The device generates 400 mV
output amplitude with 50
W
receiver resistor to V
CC
.
The V
BB
pin is internally generated voltage supply available to this
device only. For all single鈭抏nded input conditions, the unused
complementary differential input is connected to V
BB
as a switching
reference voltage. V
BB
may also rebias AC coupled inputs. When
used, decouple V
BB
via a 0.01
mF
capacitor and limit current sourcing
or sinking to 0.5 mA. When not used, V
BB
output should be left open.
http://onsemi.com
MARKING
DIAGRAM*
TBD
ALYW
QFN鈭?6
MN SUFFIX
CASE 485G
A = Assembly Location
L = Wafer Lot
Y = Year
W = Work Week
鈥?/div>
Maximum Input Clock Frequency > 10 GHz Typical
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Maximum Input Data Rate > 10 Gb/s Typical
120 ps Typical Propagation Delay
35 ps Typical Rise and Fall Times
*For additional marking information, refer to
Application Note AND8002/D.
ORDERING INFORMATION
Device
NBSG16MMN
NBSG16MMNR2
Package
3x3 mm
QFN鈭?6
3x3 mm
QFN鈭?6
Shipping鈥?/div>
123 Units / Rail
3000/Tape & Reel
Positive CML Output with Operating Range: V
CC
= 2.375 V to
3.465 V with V
EE
= 0 V
鈥?/div>
Negative CML Output with RSNECL or NECL Inputs with
Operating Range: V
CC
= 0 V with V
EE
= 鈭?.375 V to 鈭?.465 V
鈥?/div>
CML Output Level; 400 mV Peak鈭抰o鈭扨eak Output with
50
W
Receiver Resistor to V
CC
鈥?/div>
50
W
Internal Input and Output Termination Resistors
鈥燜or additional tape and reel information, refer to
Brochure BRD8011/D.
鈥?/div>
Compatible with Existing 2.5 V/3.3 V LVEP, EP, LVEL
and SG Devices
鈥?/div>
V
BB
Reference Voltage Output
漏
Semiconductor Components Industries, LLC, 2003
1
September, 2003 鈭?Rev. 1
Publication Order Number:
NBSG16M/D
