NBSG16
Product Preview
2.5V / 3.3V SiGe Differential
Receiver/Driver with
RSECL* Outputs
*Reduced Swing ECL
The SG16 is a Silicon Germanium differential receiver/driver. The
device is functionally equivalent to the EP16 and LVEP16 devices
with much higher bandwidth and lower EMI capabilities.
Inputs contain internal 50
W
termination resistors and accept
NECL (Negative ECL), PECL (Positive ECL), HSTL, GTL, TTL,
CMOS, CML, or LVDS. Outputs are RSECL (Reduced Swing ECL),
400 mV. For LVDS, CML, or CMOS outputs, use the device product
numbers NBSGL16, NBSGM16, or NBSGC16.
The V
BB
and V
MM
pins are internally generated voltage supplies
available to this device only. The V
BB
is used for single鈥揺nded NECL
or PECL inputs and the V
MM
pin is used for CMOS inputs. For all
single鈥揺nded input conditions, the unused differential input is
connected to V
BB
or V
MM
as a switching reference voltage. V
BB
or
V
MM
may also rebias AC coupled inputs. When used, decouple V
BB
and V
MM
via a 0.01
mf
capacitor and limit current sourcing or sinking
to 0.5 mA. When not used, V
BB
and V
MM
outputs should be left open.
http://onsemi.com
MARKING
DIAGRAM*
BGA鈥?6
BA SUFFIX
CASE 489
SG
16
LYW
L = Wafer Lot
Y = Year
W = Work Week
*For additional information, refer to Application Note
AND8002/D
鈥?/div>
Maximum Frequency > 12 GHz Typical
鈥?/div>
40 ps Typical Rise and Fall Times
鈥?/div>
RSPECL Output with RSPECL, PECL, HSTL, GTL, TTL, CMOS,
CML, or LVDS Inputs with Operating Range: V
CC
= 2.375 V to 3.6 V
with V
EE
= 0 V
鈥?/div>
RSNECL Output with RSNECL or NECL Inputs with
Operating Range: V
CC
= 0 V with V
EE
= 鈥?.375 V to 鈥?.6 V
鈥?/div>
RSECL Output Level (400 mV Peak鈥搕o鈥揚eak Output), Differential
Output Only
鈥?/div>
75 kW Pulldown Resistor on D and D, 36.5 kW Pullup Resistor on D
ORDERING INFORMATION
Device
NBSG16BA
NBSG16BAR2
Package
4x4
BGA鈥?6
4x4
BGA鈥?6
Shipping
810 Units/Tray
2500 Tape & Reel
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
50
W
Internal Input Resistors
Compatible with Existing 2.5 V/3.3 V LVEP, EP, and LVEL Devices
ESD Protection: (TBD)
V
BB
and V
MM
Reference Voltage Output
Meets or Exceeds JEDEC Spec EIA/JESD78 IC Latchup Test (TBD)
Moisture Sensitivity Level 3: ASE Requires Drypack
Flammability Rating: TBD
Transistor Count: 167 Devices
This document contains information on a product under development. ON Semiconductor
reserves the right to change or discontinue this product without notice.
漏
Semiconductor Components Industries, LLC, 2001
1
June, 2001 鈥?Rev. 0
Publication Order Number:
NBSG16/D
