NB100ELT23L/D Datasheet

  • NB100ELT23L/D

  • 3.3V Dual Differential LVPECL to LVTTL Translator

  • 62.34KB

  • 6頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

NB100ELT23L
3.3V Dual Differential
LVPECL to LVTTL
Translator
The NB100ELT23L is a dual differential LVPECL to LVTTL
translator. Because LVPECL (Positive ECL) levels are used, only +3.3 V
and ground are required. The small outline 8-lead package and the dual
gate design of the ELT23L makes it ideal for applications which require
the translation of a clock and a data signal.
The ELT23L is available in only the ECL 100K standard. Since
there are no LVPECL outputs or an external V
BB
reference, the
ELT23L does not require both ECL standard versions. The LVPECL
inputs are differential. Therefore, the NB100ELT23L can accept any
standard differential LVPECL input referenced from a V
CC
of +3.3 V.
http://onsemi.com
MARKING
DIAGRAMS*
8
SO鈭?
D SUFFIX
CASE 751
1
8
8
1
TSSOP鈭?
DT SUFFIX
CASE 948R
1
A
L
Y
W
= Assembly Location
= Wafer Lot
= Year
= Work Week
K23L
ALYW
KT23L
ALYW
8
1
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
2.1 ns Typical Propagation Delay
Maximum Operating Frequency > 160 MHz
24 mA LVTTL Outputs
Operating Range: V
CC
= 3.0 V to 3.6 V with GND = 0 V
Open Input Default State
Q Output Will Default LOW with Inputs Open or at GND
*For additional information, see Application Note
AND8002/D
ORDERING INFORMATION
Device
NB100ELT23LD
NB100ELT23LDR2
NB100ELT23LDT
Package
SO鈭?
SO鈭?
TSSOP鈭?
Shipping鈥?/div>
98 Units/Rail
2500 Tape & Reel
100 Units/Rail
NB100ELT23LDTR2 TSSOP鈭? 2500 Tape & Reel
鈥燜or information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specifications
Brochure, BRD8011/D.
漏
Semiconductor Components Industries, LLC, 2003
1
October, 2003 鈭?Rev. 2
Publication Order Number:
NB100ELT23L/D
