NAD1220-35 Datasheet

  • NAD1220-35

  • 12-Bit 20MSPS Sampling Analog-to-Digital Converter IP in 0.3...

  • 94.92KB

  • 12頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Product specification
12-Bit 20MSPS Sampling
Analog-to-Digital Converter IP Core
TSMC 0.35碌 2P3M
FEATURES
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
2.8-3.6V power supply
SINAD typ. 59dB for (f
in
= 5MHz)
Very low power (70mW@3.0V)
Sample rate: > 20MSPS
Internal Sample/Hold
Differential input
Low input capacitance
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
nAD1220
APPLICATIONS
Imaging
Test equipment
Computer scanners
Communications
Set top boxes
GENERAL DESCRIPTION
The nAD1220 is a compact, high-speed, very low power 12-bit monolithic analog-to-
digital converter, implemented in a 0.35碌m CMOS process. It has 12-bit resolution
with close to 10 effective bits, and more than 10 bit dynamic range for video signals.
The converter includes sample and hold. The full-scale range can be set between
鹵0.6V
and
鹵1.7V
using external references. It operates from a single 2.8-3.6V supply
- compatible with modern digital systems. Most converters in this performance range
demand at least a +5V supply. Its low distortion and high dynamic range offers the
performance needed for demanding imaging, multimedia, telecommunications and
instrumentation applications. The conversion rate can be increased to 40MHz while
keeping SINAD higher than 50dB. An evaluation kit is available, see ordering
information below.
QUICK REFERENCE DATA
Symbol
V
DD
P
D
DNL
INL
f
S
N
Parameter
supply voltage
power dissipation
differential nonlinearity
differential nonlinearity
integral nonlinearity
integral nonlinearity
conversion rate
resolution
Conditions
Ex. references
f
IN
=0.9991MHz
f
IN
=0.9991MHz
f
IN
=0.9991MHz
f
IN
=0.9991MHz
Min.
2.8
Typ.
3.3
76
Max.
3.6
鹵0.4
鹵1
鹵1
鹵3
Unit
V
mW
LSB
(10bit)
LSB
(12bit)
LSB
(10bit)
LSB
(12it)
MHz
bit
20
12
Table 1. Quick reference data
ORDERING INFORMATION
Type number
nAD1220-CORE
nAD1220-KIT
Name
CORE
KIT
Description
nAD1220 hard-core; layout available in 0.35碌m CMOS
nAD1220 evaluation kit with the nAD1220 on board
Version
c-1
k-1
Table 2. Ordering information
Main office: Nordic VLSI ASA - Vestre Rosten 81, N-7075 Tiller, Norway - Phone +4772898900 - Fax +4772898989
Branch office: Nordic VLSI ASA - P.O.Box 436 Sk酶yen, N-0212 Oslo, Norway - Phone +4722511050 - Fax +4722511099
Revision: 3.3
Page 1 of 12
February 27th 2001
