NAD1040-25 Datasheet

  • NAD1040-25

  • 10-Bit 40MSPS Sampling Analog-to-Digital Converter IP in 0.2...

  • 11頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

PRODUCT SPECIFICATION
10-Bit 40MSPS Sampling
Analog-to-Digital Converter
FEATURES
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
2.5V power supply
SNR typ 60dB for (f
in
= 10MHz)
Low power (79mW@2.5V)
Sample rate:10 - 40MSPS
Frequency dependent biasing
Internal/sample hold
Differential input
Low input capacitance
Evaluation Board Available
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
nAD1040-25
APPLICATIONS
Imaging
Test equipment
Computer scanners
Communications
Set top boxes
Video products
GENERAL DESCRIPTION
The nAD1040-25 is a compact, high-speed, low power 10-bit monolithic analog-to-
digital converter, implemented in the TSMC Mixed-Signal MiM CMOS process. It
has 10-bit resolution with 9.5 effective bits, and close to 11 bit dynamic range for
video frequency signals. The converter includes a high bandwidth sample and hold.
The full scale range is
鹵1V.
The full scale range can be set between
鹵0.5V
and
鹵1V.
It operates from a single 2.5V supply. Its low distortion and high dynamic range offers
the performance needed for demanding imaging, multimedia, telecommunications and
instrumentation applications.
The bias current level for the ADC is automatically adjusted based on the clock input
frequency. Hence, the power dissipation of the device is continuously minimised for
the current operation frequency.
QUICK REFERENCE DATA
Symbol
V
DD
I
DD
P
D
P
D
P
D
DNL
INL
f
S
N
Parameter
supply voltage
supply current
(40 MSPS)
power dissipation
(40 MSPS)
power dissipation
(10 MSPS)
power dissipation
(sleep mode)
differential nonlinearity
integral nonlinearity
conversion rate
resolution
Conditions
Min.
2.25
Typ.
2.5
28
70
20
1.5
Max.
2.75
Unit
V
mA
mW
mW
mW
Except digital
output drivers
Except digital
output drivers
Except digital
output drivers
f
IN
=0.9991MHz
f
IN
=0.9991MHz
10
鹵0.5
鹵1
40
10
LSB
LSB
MHz
bit
Table 1. Quick reference data
Main office: Nordic VLSI ASA - Vestre Rosten 81, N-7075 Tiller, Norway - Phone +4772898900 - Fax +4772898989
Branch office: Nordic VLSI ASA - P.O.Box 436 Sk酶yen, N-0212 Oslo, Norway - Phone +4722511050 - Fax +4722511099
Revision: 2.1
Page 1 of 11
February 8th, 2001
