NAD1040-18 Datasheet

  • NAD1040-18

  • 10-Bit 40MSPS Sampling Analog-to-Digital Converter IP in 0.1...

  • 85.69KB

  • 11頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

PRODUCT SPECIFICATION
10-Bit 40MSPS Sampling
Analog-to-Digital Converter
FEATURES
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
1.8V power supply
SNR typ 60dB for (f
in
= 10MHz)
Low power (27mW @ 1.8V and
40MSPS)
Frequency dependent biasing
Internal Sample/Hold
Differential input
Low input capacitance
Power Down and Sleep Mode
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
nAD1040-18
APPLICATIONS
Imaging
Test equipment
Computer scanners
Wireless communication
Powerline communication
Set top boxes
Video products
GENERAL DESCRIPTION
The nAD1040-18 is a compact, high-speed, low power 10-bit monolithic analog-to-
digital converter, implemented in a 0.18碌m single poly CMOS process with MiM
capacitor option. The converter includes a high bandwidth sample and hold. Using
internal references, the full scale range is
鹵0.75V.
The full scale range can be set
between
鹵0.5V
and
鹵0.75V
using external references. It operates from a single 1.8V
supply. Its low distortion and high dynamic range offers the performance needed for
demanding imaging, multimedia, telecommunications and instrumentation
applications. The bias current level for the ADC is automatically adjusted based on
the clock input frequency. Hence, the power dissipation of the device is continuously
minimised for the current operation frequency.
QUICK REFERENCE DATA
Symbol
V
DD
I
DD
P
D
P
D
DNL
INL
f
S
N
Parameter
Supply voltage
Supply current
(40 MSPS)
Power dissipation
(10 MSPS)
Power dissipation
(40 MSPS)
Differential
nonlinearity
Integral nonlinearity
Conversion rate
Resolution
Conditions
Min.
1.6
Typ.
1.8
15
8
27
Max.
2.0
Unit
V
mA
mW
mW
Except digital
output drivers
Except digital
output drivers
f
IN
=0.9991MHz
f
IN
=0.9991MHz
鹵0.5
鹵0.75
40
10
LSB
LSB
MHz
bit
Table 1. Quick reference data
Main office: Nordic VLSI ASA - Vestre Rosten 81, N-7075 Tiller, Norway - Phone +4772898900 - Fax +4772898989
Revision: 3.0
Page 1 of 11
August 31
st
2001
