MZ9310/MZ9310C
TRIPLE-BALANCED MIXER
路 LO 2 TO 18 GHz
RF 2 TO 18 GHz
路 IF 0.03 TO 5 GHz
路 LO DRIVE +10 dBm (nominal)
路 MINIATURE PACKAGE
路 WIDE BANDWIDTH
路 AVAILABLE WITH FIELD REPLACEABLE CONNECTORS
Specifications (Rev. Date: 12/01)*
Characteristics
SSB Conversion Loss & SSB Noise Figure (max.)
f
R
=
4 to 18 GHz,
f
L
=
4 to 18 GHz,
f
I
=
0.03 to 1 GHz
f
R
=
3 to 18 GHz,
f
L
=
3 to 18 GHz,
f
I
=
0.03 to 2 GHz
f
R
=
2 to 18 GHz,
f
L
=
2 to 18 GHz,
f
I
=
0.03 to 5 GHz
f
R
=
f
L
=
f
I
=
Isolation (min.)
L to R
f
L
=
2 to 4 GHz
f
L
=
4 to 18 GHz
f
L
=
L to I
f
L
=
2 to 18 GHz
f
L
=
f
L
=
R to I
f
R
=
f
R
=
1 dB Conversion Compression
f
L
@
+10 dBm
f
L
@
Input IP3
f
R1
=
3 GHz @ -10 dBm
f
R2
=
3.01 GHz @ -10 dBm
f
L
=
5 GHz @ 10 dBm
f
R1
=
17.99 GHz @ -10 dBm
f
L
=
14 GHz @ 10 dBm
f
R1
=
f
L
=
f
R2
=
18 GHz @ -10 dBm
f
R2
=
Typical
7 dB
7.5 dB
8 dB
+25擄C
擄
Guaranteed
-54擄 to +85擄C
擄
擄
9 dB
9.5 dB
11 dB
8.5 dB
9 dB
10.5 dB
20 dB
25 dB
30 dB
12 dB
16 dB
16 dB
10 dB
14 dB
14 dB
+6 dBm
+16 dBm
+13 dBm
Measured in a 50-ohm system with nominal LO drive and downconverter application only, unless otherwise specified. Subject to change without notice.
Absolute Maximum Ratings
Operating Temperature
Storage Temperature
Peak Input Power
Peak Input Current
Outline Drawing(s)
-54擄C to 100擄C
-65擄C to 100擄C
26 dBm max. @ +25擄, 23擄C
mA DC
Package
VPAC
SMA
Figure
JD
JC
Model
MZ9310
MZ9310C
Specifications subject to change without notice.
鈥?/div>
North America: 1-800-366-2266
Visit www.macom.com for complete contact and product information.
