19-2057; Rev 0; 5/01
MXL1543 Evaluation Kit
General Description
The MXL1543 evaluation kit (EV kit) combines Maxim鈥檚
multiprotocol clock/data transceiver (MXL1543), control
transceiver (MXL1544), and cable terminator (MXL1344A)
chips. This chipset forms a complete software-selectable
multiprotocol data terminal equipment (DTE) or data com-
munications equipment (DCE) interface port.
The MXL1543, MXL1544, and MXL1344A chipset sup-
ports V.28 (RS-232), V.11(RS-449/V.36, EIA530, EIA530-
A, X.21), and V.35 protocols. NET1, NET2, TBR-1, and
TBR-2 compliance has been certified by TUV Telecom
Services, Inc. Internal charge pumps allow this kit to oper-
ate off a single +5V supply.
The MXL1543 EV kit was designed to take advantage of
the chipset鈥檚 flow-through pinout. This kit includes a 40-
pin header (logic signals), a female DB25 connector (pro-
tocol signals), three SMA connectors (high-speed logic
signals), and scope probe connectors for measuring the
high-speed data signals (logic and protocol signals).
The MXL1543 EV kit can evaluate the MAX3175 and is
used in place of the MXL1544. Contact Maxim to order
samples of the MAX3175CAI. No further changes
are required to the board to evaluate the MAX3175.
Features
o
Programmable Transceiver Supports
V.28 (RS-232)
V.11 (RS-449/V.36, EIA530, EIA530-A, X.21)
V.35
o
True Fail-Safe Receiver Inputs
o
Certified TBR-1 and TBR-2 Compliant
o
Certified NET1 and NET2 Compliant
o
Programmable Cable Termination (MXL1344A)
o
Fully Assembled and Tested
Evaluates: MXL1543/MXL1544/MAX3175/MXL1344A
Ordering Information
PART
MXL1543EVKIT
TEMP. RANGE
0擄C to +70擄C
IC PACKAGE
28 SSOP (2),
24 SSOP
Component List
DESIGNATION
C1, C2, C5,
C9鈥揅13
QTY
8
DESCRIPTION
1碌F, 10V ceramic capacitors
(0805)
TDK C2012X5R1A105M
4.7碌F, 10V ceramic capacitors
(1206)
TDK C3216X5R1A475M
100pF ceramic capacitors (0603)
0.1碌F ceramic capacitors (0603)
0.1碌F ceramic capacitor (0805)
47碌F, 16V tantalum capacitor (D
case) AVX TPSD476M016R0200
49.9鈩?鹵1% resistors (0805)
1.5k鈩?鹵5% resistors (0805)
Red LED
Green LED
Yellow LED
MXL1543CAI (28-pin SSOP)
MXL1544CAI (28-pin SSOP)
MXL1344ACAG (24-pin SSOP)
Inverting LED drivers (20-pin SO)
TI SN74HC240DW or
Motorola MC74HC240ADW
J3, J4, J5
3
DESIGNATION
RXD/TXD,
RXC/SCTE,
TXC/ N/A,
N/A /TXC,
SCTE/RXC,
TXD/RXD,
RXDA/TXDA,
RXDB/TXDB,
RXCA/SCTEA,
RXCB/SCTEB,
TXCA/TXCA,
TXCB/TXCB,
SCTEA/RXCA,
SCTEB/RXCB,
TXDA/RXDA,
TXDB/RXDB
J1
J2
QTY
DESCRIPTION
C3, C4
C6, C7, C8
C14, C15
C16
C17
R1, R2, R3
R4鈥揜19
D1鈥揇6
D7鈥揇12
D13鈥?6
U1
U2
U3
U4, U5
2
3
2
1
1
3
16
6
6
4
1
1
1
2
16
Scope probe connectors
(top mount, 3.5mm ground
cylinder)
Tektronix 131-4244-00 (qty 100)
131-5031-00 (qty 25)
1
1
40-pin header (2x20) 0.1in center
DB25 right-angle female connector
AMP AMP0012 747846-4
SMA connectors (PC edge mount)
EFJohnson 142-0701-801
________________________________________________________________
Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim鈥檚 website at www.maxim-ic.com.
