MX7535 Datasheet

  • MX7535

  • Microprocessor-Compatible.14-Bit DACs

  • 16頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

19-1116; Rev 1; 11/96
Microprocessor-Compatible,
14-Bit DACs
_______________General Description
The MX7534/MX7535 are high-performance, CMOS,
monolithic, 14-bit digital-to-analog converters (DACs).
Wafer-level, laser-trimmed, thin-film resistors and tempera-
ture-compensated NMOS switches assure operation over
the full operating temperature range with exceptional lin-
ear and gain stability.
The MX7534 accepts right-justified data in two bytes from
an 8-bit bus, while the MX7535 operates with a 14-bit data
bus with separate MS-byte and LS-byte select controls. In
addition, all digital inputs are compatible with both TTL and
5V CMOS-logic levels. The MX7534/MX7535 are intended
for unipolar operation, but may be operated as bipolar
DACs with additional external components. Both devices
are protected against CMOS latchup, and neither requires
the use of external Schottky protection diodes.
The MX7534 is available in 20-pin narrow (0.3") DIP, wide
SO, or PLCC packages. The MX7535 is available in
28-pin, 600 mil wide DIP, wide SO, or PLCC packages.
____________________________Features
o
14-Bit Monotonic Over Full Temperature Range
o
Full 4-Quadrant Multiplication
o
碌P-Compatible, Double-Buffered Inputs
o
Exceptionally Low Gain Tempco (2.5ppm/擄C)
o
Low Output Leakage (<20nA) Over Temp.
o
Low Power Consumption
o
TTL and CMOS Compatible
MX7534/MX7535
______________Ordering Information
PART
MX7534KN
MX7534JN
MX7534KCWP
MX7534JCWP
MX7534KP
MX7534JP
MX7534J/D
MX7534BQ
MX7534AQ
MX7534BD
MX7534AD
MX7534KEWP
MX7534JEWP
MX7534TQ
MX7534SQ
MX7534TD
MX7534SD
TEMP. RANGE
0擄C to +70擄C
0擄C to +70擄C
0擄C to +70擄C
0擄C to +70擄C
0擄C to +70擄C
0擄C to +70擄C
0擄C to +70擄C
-25擄C to +85擄C
-25擄C to +85擄C
-25擄C to +85擄C
-25擄C to +85擄C
-40擄C to +85擄C
-40擄C to +85擄C
-55擄C to +125擄C
-55擄C to +125擄C
-55擄C to +125擄C
-55擄C to +125擄C
PIN-PACKAGE INL (LSBs)
20 Plastic DIP
20 Plastic DIP
20 SO
20 SO
20 PLCC
20 PLCC
Dice*
20 CERDIP
20 CERDIP
20 Ceramic SB
20 Ceramic SB
20 SO
20 SO
20 CERDIP
20 CERDIP
20 Ceramic SB
20 Ceramic SB
鹵1
鹵2
鹵1
鹵2
鹵1
鹵2
鹵2
鹵1
鹵2
鹵1
鹵2
鹵1
鹵2
鹵1
鹵2
鹵1
鹵2
________________________Applications
Machine and Motion Control Systems
Automatic Test Equipment
Digital Audio
碌P-Controlled Calibration Circuitry
Programmable-Gain Amplifiers
Digitally Controlled Filters
Programmable Power Supplies
Ordering Information continued at end of data sheet.
*Dice
are tested at +25擄C, DC parameters only.
_________________Pin Configurations
TOP VIEW
REF 1
RFB 2
IOUT 3
AGNDS 4
AGNDF 5
DGND 6
D7 7
D6
8
20 V
SS
19 V
DD
18 CS
17 WR
_______________Functional Diagrams
V
DD
19
REF
1
14-BIT DAC
14
DAC REGISTER
6
MS
INPUT
REGISTER
8
LS
INPUT
REGISTER
MX7534
2
RFB
3
IOUT
4 AGNDS
5 AGNOF
15
A1
16
A0
18 CS
17
WR
MX7534
16 A0
15 A1
14 D0
13 D1
12 D2
11 D3
CONTROL
LOGIC
D5 9
D4 10
DIP/SO/PLCC/Ceramic SB
MX7535 at end of data sheet.
7鈥?4
D7鈥揇0
6
DGND
20
V
SS
Functional diagrams continued at end of data sheet.
________________________________________________________________
Maxim Integrated Products
1
For free samples & the latest literature: http://www.maxim-ic.com, or phone 1-800-998-8800
