MwT-0820S-5G1/0820Z-5G1
8.0-20.0 GHz Balanced Amplifier Module
www.mwtinc.com
Email: info@mwtinc.com
TYPICAL SPECIFICATIONS AT 25 C
16.0 dBm P-1dB
9.0 dB SMALL SIGNAL GAIN
15.0 dB INPUT/OUTPUT RETURN LOSS
90 mA @ +8V
USES TWO MwT-5 GaAs FET DEVICES
5.0 dB NOISE FIGURE
Typical Input/Output
Return Loss (dB)
5
10
15
20
25
8
14
Frequency (GHz)
20
S
11
S
22
Typical Small
Signal Gain (dB)
10.0
9.0
8.0
8
14
Frequency (GHz)
20
ELECTRICAL SPECIFICATIONS
SYMBOL
FREQ
SSG
G/ F
G/ T
P-1dB
PSAT
P/ T
IP3
2nd HAR
2nd HAR
NF
VSWR IN
VSWR OUT
ISO
VDD
IDD
RTH
PARAMETERS
(Ta=25 C)
UNITS
GHz
dB
+/-dB
dB/ C
dBm
dBm
dB/ C
dBm
dBc
dBc
dB
-----
-----
dB
+V
mA
C/W
MIN
8.0
8.0
TYP
MAX
20.0
9.0
0.4
-.012
16.0
18.0
-.008
26.0
-21.0
-16.0
6.0
1.5:1
1.5:1
-28.0
8.0
90.0
166.0
0.6
Frequency Range
Small Signal Gain
SSG Flatness
SSG Variation over Temperature
Output Power at 1dB Compression
Output Power at 6 dB Compression
P-1dB Variation over Temperature
Third Order Intercept Point
2nd Harmonic at Pout=16.0 dBm
2nd Harmonic at Pout=18.0 dBm
Noise Figure
Input VSWR
Output VSWR
Reverse Isolation
Power Supply Voltage
Small Signal Module Current
Thermal Resistance Including FET*
14.0
7.5
1.7:1
1.7:1
8.1
110.0
7.9
* When calculating Tch, use FET Vds = 6.0 volts and FET ds = 45 mA
4268 Solar Way Fremont California 94538 Phone: (510) 651-6700 Fax: (510) 651-2208
651-2208
All rights reserved. MicroWave Technology, Inc. All specifications subject to change without notice.
