MwT-0618S-TCM/0618Z-TCM
6.0-18.0 GHz Balanced Temp. Comp. Module
www.mwtinc.com
Email: info@mwtinc.com
TYPICAL SPECIFICATIONS AT 25 C
FLAT FREQUENCY RESPONSE
LOW INSERTION LOSS AT ZERO BIAS
BUILT-IN THERMISTOR FOR TEMPERATURE
COMPENSATION
HIGH DYNAMIC RANGE
FLEXIBLE ADJUSTMENT TO SUIT DIFFERENT
TEMPERATURE COMPENSATION REQUIREMENTS
LOW VSWR
1.0
2.0
3.0
4.0
MIN ATT (@Zero Bias)
Typical Input/Output
Return Loss (dB)
5
10
15
20
25
6
S
22
12
Frequency (GHz)
18
S
11
Typical Insertion Loss (dB)
MAX ATTENUATION
10.0
11.0
12.0
13.0
2
3
4
5
Frequency (GHz)
6
ELECTRICAL SPECIFICATIONS
SYMBOL
FREQ
IL
ATTEN.
IL/ F
VSWR IN
VSWR OUT
VDC
IDC
PARAMETERS
(Ta=25 C)
UNITS
GHz
dB
dB
+/-dB
-----
-----
+V
mA
MIN
6.0
12.0
2.5
13.0
0.6
1.6:1
1.6:1
8.0
10.0
TYP
MAX
18.0
3.0
0.8
1.8:1
1.8:1
9.0
20.0
Frequency Range
Insertion Loss @ min Attentuation (No Bias)
Insertion Loss @ max Attentuation
Insertion Flatness over Freq @ any Atten.
Input VSWR
Output VSWR
Power Supply Voltage
DC Current
6.0
