MwT-0618S-5G2/0618Z-5G2
6.0-18.0 GHz Balanced Amplifier Module
www.mwtinc.com
Email: info@mwtinc.com
TYPICAL SPECIFICATIONS AT 25 C
18.0 dBm P-1dB
10.5 dB SMALL SIGNAL GAIN
15.0 dB INPUT/OUTPUT RETURN LOSS
100 mA @ +8V
USES TWO MwT-5HG GaAs FET DEVICES
5.5 dB NOISE FIGURE
Typical Input/Output
Return Loss (dB)
5
10
15
20
25
6
12
Frequency (GHz)
18
S22
S11
Typical Small
Signal Gain (dB)
11.0
10.0
9.0
6
12
Frequency (GHz)
18
ELECTRICAL SPECIFICATIONS
SYMBOL
FREQ
SSG
G/ F
G/ T
P-1dB
PSAT
P/ T
IP3
2nd HAR
2nd HAR
NF
VSWR IN
VSWR OUT
ISO
VDD
IDD
RTH
PARAMETERS
(Ta=25 C)
UNITS
GHz
dB
+/-dB
dB/ C
dBm
dBm
dB/ C
dBm
dBc
dBc
dB
-----
-----
dB
+V
mA
C/W
MIN
6.0
10.5
TYP
MAX
18.0
10.5
0.4
-.012
18.0
19.5
-.008
28.0
-21.0
-16.0
5.0
1.5:1
1.5:1
-30.0
8.0
100.0
166.0
0.6
Frequency Range
Small Signal Gain
SSG Flatness
SSG Variation over Temperature
Output Power at 1dB Compression
Output Power at 6 dB Compression
P-1dB Variation over Temperature
Third Order Intercept Point
2nd Harmonic at Pout=18.0 dBm
2nd Harmonic at Pout=19.5 dBm
Noise Figure
Input VSWR
Output VSWR
Reverse Isolation
Power Supply Voltage
Small Signal Module Current
Thermal Resistance Including FET*
15.5
6.0
1.7:1
1.7:1
8.1
120.0
7.9
* When calculating Tch, use FET Vds = 6.0 volts and FET ds = 50mA
4268 Solar Way Fremont California 94538 Phone: (510) 651-6700 Fax: (510) 651-2208
651-2208
All rights reserved. MicroWave Technology, Inc. All specifications subject to change without notice.
