MwT-0618S-12P1/0618Z-12P1
6.0-18.0 GHz Balanced Amplifier Module
www.mwtinc.com
Email: info@mwtinc.com
TYPICAL SPECIFICATIONS AT 25 C
27.0 dBm P-1dB
4.0 dB SMALL SIGNAL GAIN
15.0 dB INPUT/OUTPUT RETURN LOSS
350 mA @ +8V
USES TWO MwT-12HP GaAs FET DEVICES
7.5 dB NOISE FIGURE
Typical Output Power
P-1dB (dBm)
29
28
27
26
25
6
12
Frequency (GHz)
18
Typical Small
Signal Gain (dB)
5.0
4.0
3.0
6
12
Frequency (GHz)
18
ELECTRICAL SPECIFICATIONS
SYMBOL
FREQ
SSG
G/ F
G/ T
P-1dB
PSAT
P/ T
IP3
2nd HAR
2nd HAR
NF
VSWR IN
VSWR OUT
ISO
VDD
IDD
RTH
PARAMETERS
(Ta=25 C)
UNITS
GHz
dB
+/-dB
dB/ C
dBm
dBm
dB/ C
dBm
dBc
dBc
dB
-----
-----
dB
+V
mA
C/W
MIN
6.0
3.7
TYP
MAX
18.0
4.0
0.4
-.012
27.0
28.0
-.008
37.0
-21.0
-16.0
7.5
1.5:1
1.5:1
-20.0
8.0
350.0
55.0
0.6
Frequency Range
Small Signal Gain
SSG Flatness
SSG Variation over Temperature
Output Power at 1dB Compression
Output Power at 6 dB Compression
P-1dB Variation over Temperature
Third Order Intercept Point
2nd Harmonic at Pout=27.0 dBm
2nd Harmonic at Pout=28.0 dBm
Noise Figure
Input VSWR
Output VSWR
Reverse Isolation
Power Supply Voltage
Small Signal Module Current
Thermal Resistance Including FET*
26.0
1.7:1
1.7:1
8.1
450.0
7.9
* When calculating Tch, use FET Vds = 6.0 volts and FET ds = 175 mA
