MW4IC001MR4 Datasheet

  • MW4IC001MR4

  • MW4IC001MR4 800-2170 MHz. 900 mW. 28 V. W-CDMA. RF LDMOS Wid...

  • 12頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

MOTOROLA
SEMICONDUCTOR TECHNICAL DATA
Freescale Semiconductor, Inc.
Order this document
by MW4IC001MR4/D
The Wideband IC Line
RF LDMOS Wideband Integrated
Power Amplifier
The MW4IC001MR4 wideband integrated circuit is designed for use as a
distortion signature device in analog predistortion systems. It uses Motorola鈥檚
newest High Voltage (26 to 28 Volts) LDMOS IC technology. Its wideband On
Chip design makes it usable from 800 MHz to 2200 MHz. The linearity
performances cover all modulations for cellular applications: GSM EDGE,
TDMA, CDMA and W - CDMA.
鈥?/div>
Typical CW Performance at 2170 MHz, 28 Volts, I
DQ
= 12 mA
Output Power 鈥?900 mW PEP
Power Gain 鈥?13 dB
Efficiency 鈥?38%
鈥?/div>
High Gain, High Efficiency and High Linearity
鈥?/div>
Designed for Maximum Gain and Insertion Phase Flatness
鈥?/div>
Excellent Thermal Stability
鈥?/div>
Characterized with Series Equivalent Large - Signal Impedance Parameters
鈥?/div>
In Tape and Reel. R4 Suffix = 100 Units per 12 mm, 7 inch Reel.
MW4IC001MR4
800 - 2170 MHz, 900 mW, 28 V
W - CDMA
RF LDMOS WIDEBAND
INTEGRATED POWER AMPLIFIER
Freescale Semiconductor, Inc...
CASE 466 - 03, STYLE 1
PLD - 1.5
PLASTIC
MAXIMUM RATINGS
Rating
Drain - Source Voltage
Gate - Source Voltage
Total Device Dissipation @ T
C
= 25擄C
Derate above 25擄C
Storage Temperature Range
Operating Junction Temperature
Symbol
V
DSS
V
GS
P
D
T
stg
T
J
Characteristic
Thermal Resistance, Junction to Case @ 85擄C
Symbol
R
胃JC
Value
65
- 0.5, +15
4.58
0.037
- 65 to +150
150
Unit
Vdc
Vdc
W
W/擄C
擄C
擄C
THERMAL CHARACTERISTICS
Value (1)
27.3
Unit
擄C/W
ESD PROTECTION CHARACTERISTICS
Test Conditions
Human Body Model
Machine Model
Charge Device Model
Class
0 (Minimum)
M1 (Minimum)
C2 (Minimum)
(1) Refer to AN1955/D,
Thermal Measurement Methodology of RF Power Amplifiers.
Go to http://www.motorola.com/semiconductors/rf .
Select Documentation/Application Notes - AN1955.
NOTE -
CAUTION
- MOS devices are susceptible to damage from electrostatic charge. Reasonable precautions in handling and
packaging MOS devices should be observed.
REV 2
MOTOROLA RF
錚?/div>
Motorola, Inc. 2004
DEVICE DATA
For More Information On This Product,
Go to: www.freescale.com
MW4IC001MR4
1

MW4IC001MR4 產品屬性

  • 100

  • RF/IF 和 RFID

  • RF 放大器

  • -

  • 800MHz ~ 2.1GHz

  • 29.3dBm（850mW）

  • 13dB

  • -

  • 手機，CDMA，EDGE，GSM，TDMA，W-CDMA

  • 28V

  • 12mA

  • 2.17GHz

  • PLD-1.5

  • 帶卷 (TR)
