MVTX2604

Managed 24-Port 10/100 Mb + 2 Port 1 Gb

Ethernet Switch

Data Sheet

Features

鈥?/div>

Integrated Single-Chip 10/100/1000 Mbps

Ethernet Switch

24 10/100 Mbps Autosensing, Fast Ethernet

Ports with RMII or Serial Interface (7WS). Each

port can independently use one of the two

interfaces

2 Gigabit Ports with GMII, PCS, 10/100 and

stacking (2 G per port) interface options per port

Stacking port supports hot swap in managed

configuration

Supports 8/16-bit CPU interface in managed

mode

Serial interface in unmanaged mode

Supports two Frame Buffer Memory domains with

SRAM at 100 MHz

Supports memory size 2 MB, or 4 MB

鈥?For 24 + 2, two SRAM domains (2 MB or 4 MB) are

required.

鈥?For 24 + 2 stacking (2 G per stacking port), two ZBT

domains (2 MB or 4 MB) are required

February 2004

Ordering Information

MVTX2604AG

553 Pin HSBGA

-40擄C to 85擄C

鈥?/div>

Provides port based and ID tagged VLAN

support (IEEE 802.1Q), up to 255 VLANs

Supports IP Multicast with IGMP snooping

Supports spanning tree with CPU, on per port or

per VLAN basis

Packet Filtering and Port Security

鈥?Static address filtering for source and/or destination

MAC

鈥?Static MAC address not subject to aging

鈥?/div>

Applies centralized shared memory architecture

Up to 64 K MAC addresses

Maximum throughput is 6.4 Gbps non-blocking

High performance packet forwarding (19.047 M

packets per second) at full wire speed

VLAN 1 MCT

Secure mode freezes MAC address learning

Each port may independently use this mode

Full Duplex Ethernet IEEE 802.3x Flow Control

Backpressure flow control for Half Duplex ports

Supports Ethernet multicasting and broadcasting

and flooding control

Supports per-system option to enable flow

control for best effort frames even on QoS-

enabled ports

Frame Data Buffer A

SRAM (1 M / 2 M)

VLAN 1 MCT

Frame Data Buffer B

SRAM (1 M / 2 M)

FDB Interface

LED

FCB

Frame Engine

Engine

MCT

Link

24 x 10 / 100

RMII

Ports 0 - 23

GMII/

PCS

Port

GMII/

PCS

Port

Management

Module

16-bit

Parallel /

Serial

Figure 1 - MVTX2604 System Block Diagram

Zarlink Semiconductor Inc.

Zarlink, ZL and the Zarlink Semiconductor logo are trademarks of Zarlink Semiconductor Inc.
