MURB1620CT/D Datasheet

  • MURB1620CT/D

  • SWITCHMODE? Power Rectifier

  • 68.60KB

  • 8頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

MURB1620CT
Preferred Device
SWITCHMODE鈩?/div>
Power Rectifier
D
2
PAK Power Surface Mount Package
Designed for use in switching power supplies, inverters and as free
wheeling diodes, these state鈥搊f鈥搕he鈥揳rt devices have the following
features:
http://onsemi.com
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Package Designed for Power Surface Mount Applications
Ultrafast 35 Nanosecond Recovery Times
175擄C Operating Junction Temperature
Epoxy Meets UL94, V
O
@ 1/8鈥?/div>
High Temperature Glass Passivated Junction
Low Leakage Specified @ 150擄C Case Temperature
Short Heat Sink Tab Manufactured 鈥?Not Sheared!
Similar in Size to Industrial Standard TO鈥?20 Package
ULTRAFAST
RECTIFIER
16 AMPERES
200 VOLTS
1
4
3
Mechanical Characteristics
鈥?/div>
Case: Epoxy, Molded
鈥?/div>
Weight: 1.7 grams (approximately)
鈥?/div>
Finish: All External Surfaces Corrosion Resistant and Terminal
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Leads are Readily Solderable
Lead and Mounting Surface Temperature for Soldering Purposes:
260擄C Max. for 10 Seconds
Shipped 50 units per plastic tube
Available in 24 mm Tape and Reel, 800 units per reel by adding a
鈥淭4鈥?suffix to the part number
Marking: U1620
1
3
D
2
PAK
CASE 418B
STYLE 3
4
MAXIMUM RATINGS
(Per Leg)
Rating
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
Average Rectified Forward Current
(Rated V
R
, T
C
= 150擄C) Total Device
Peak Repetitive Forward Current
(Rated V
R
, Square Wave,
20 kHz, T
C
= 150擄C)
Non鈥揜epetitive Peak Surge Current
(Surge Applied at Rated Load
Conditions Halfwave, Single
Phase, 60 Hz)
Operating Junction and Storage
Temperature Range
Symbol
V
RRM
V
RWM
V
R
I
F(AV)
I
FM
Value
200
Unit
V
MARKING DIAGRAM
U1620
8.0
16
16
A
U1620 = Device Code
A
I
FSM
100
A
ORDERING INFORMATION
Device
Package
D
2
PAK
D
2
PAK
Shipping
50 Units/Rail
800/Tape & Reel
T
J
, T
stg
鈥?5 to +175
擄C
MURB1620CT
MURB1620CTT4
Preferred
devices are recommended choices for future use
and best overall value.
漏
Semiconductor Components Industries, LLC, 2001
1
April, 2001 鈥?Rev. 3
Publication Order Number:
MURB1620CT/D
