MUR8100E, MUR880E

MUR8100E is a Preferred Device

SWITCHMODE鈩?/div>

Power Rectifiers

Ultrafast 鈥淓鈥欌€?Series with High Reverse

Energy Capability

. . . designed for use in switching power supplies, inverters and as

free wheeling diodes, these state鈥搊f鈥搕he鈥揳rt devices have the

following features:

http://onsemi.com

鈥?/div>

20 mjoules Avalanche Energy Guaranteed

鈥?/div>

Excellent Protection Against Voltage Transients in Switching

鈥?/div>

Inductive Load Circuits

Ultrafast 75 Nanosecond Recovery Time

175擄C Operating Junction Temperature

Popular TO鈥?20 Package

Epoxy Meets UL94, V

@ 1/8鈥?/div>

Low Forward Voltage

Low Leakage Current

High Temperature Glass Passivated Junction

Reverse Voltage to 1000 Volts

ULTRAFAST RECTIFIERS

8.0 AMPERES

800鈥?000 VOLTS

Mechanical Characteristics:

鈥?/div>

Case: Epoxy, Molded

鈥?/div>

Weight: 1.9 grams (approximately)

鈥?/div>

Finish: All External Surfaces Corrosion Resistant and Terminal

Leads are Readily Solderable

鈥?/div>

Lead Temperature for Soldering Purposes:

260擄C Max. for 10 Seconds

鈥?/div>

Shipped 50 units per plastic tube

鈥?/div>

Marking: U880E, U8100E

MAXIMUM RATINGS

Rating

Peak Repetitive Reverse Voltage

Working Peak Reverse Voltage

DC Blocking Voltage

MUR880E

MUR8100E

Average Rectified Forward Current

(Rated V

, T

= 150擄C)

Total Device

Peak Repetitive Forward Current

(Rated V

, Square Wave,

20 kHz, T

= 150擄C)

Non鈥揜epetitive Peak Surge Current

(Surge Applied at Rated Load

Conditions Halfwave, Single

Phase, 60 Hz)

Operating Junction and Storage

Temperature Range

Symbol

RRM

RWM

F(AV)

Value

Unit

800

1000

8.0

TO鈥?20AC

CASE 221B

PLASTIC

MARKING DIAGRAM

U8x0E

U8x0E = Device Code

= 8 or 10

ORDERING INFORMATION

Device

Package

TO鈥?20

Shipping

50 Units/Rail

FSM

100

MUR8100E

MUR880E

, T

stg

鈥?5 to +175

擄C

Preferred

devices are recommended choices for future use

and best overall value.

漏

Semiconductor Components Industries, LLC, 2000

October, 2000 鈥?Rev. 1

Publication Order Number:

MUR8100E/D
