MUR240

Preferred Device

SWITCHMODE鈩?/div>

Power Rectifier

. . . designed for use in switching power supplies, inverters and as

free wheeling diodes, these state- of- the- art devices have the

following features:

鈥?/div>

Ultrafast Recovery Times

175擄C Operating Junction Temperature

Low Forward Voltage

Low Leakage Current

High Temperature Glass Passivated Junction

http://onsemi.com

Mechanical Characteristics

ULTRAFAST

RECTIFIER

2 AMPERES

400 VOLTS

鈥?/div>

Case: Epoxy, Molded

鈥?/div>

Weight: 0.4 gram (approximately)

鈥?/div>

Finish: All External Surfaces Corrosion Resistant and Terminal

鈥?/div>

Leads are Readily Solderable

Lead and Mounting Surface Temperature for Soldering Purposes:

220擄C Max. for 10 Seconds, 1/16鈥?from case

Shipped in plastic bags, 1000 per bag

Available Tape and Reeled, 5000 per reel, by adding a 鈥淩L鈥欌€?suffix to

the part number

Polarity: Cathode Indicated by Polarity Band

Marking: MUR240

AXIAL LEAD

CASE 059-10

PLASTIC

MAXIMUM RATINGS

Rating

Peak Repetitive Reverse Voltage

Working Peak Reverse Voltage

DC Blocking Voltage

Average Rectified Forward Current

(Note 1) (Square Wave Mounting

Method #3 Per Note 1)

Non-Repetitive Peak Surge Current

(Surge applied at rated load conditions,

halfwave, single phase, 60 Hz)

Operating Junction Temperature and

Storage Temperature Range

Symbol

RRM

RWM

F(AV)

Value

400

2.0 @

= 85擄C

Unit

MUR

240

MUR240 = Device Code

MARKING DIAGRAM

FSM

ORDERING INFORMATION

, T

stg

- 65 to

+175

擄C

Device

MUR240

MUR240RL

Package

Axial Lead

Shipping

1000 Units/Bag

5000/Tape & Reel

1. Pulse Test: Pulse Width = 300

ms,

Duty Cycle

鈮?/div>

2.0%.

Preferred

devices are recommended choices for future use

and best overall value.

漏

Semiconductor Components Industries, LLC, 2003

April, 2003 - Rev. 4

Publication Order Number:

MUR240/D

標準包裝
5,000
類別
分離式半導體產品
家庭
單二極管/整流器
系列
SWITCHMODE™
二極管類型
標準
電壓 - (Vr)（最大）
400V
電流 - 平均整流 (Io)
2A
電壓 - 在 If 時為正向 (Vf)（最大）
1.3V @ 2A
速度
快速恢復 = 200mA（Io）
反向恢復時間
65ns
電流 - 在 Vr 時反向漏電
5µA @ 400V
電容@ Vr, F
-
安裝類型
通孔
封裝/外殼
DO-204AL，DO-41，軸向
供應商設備封裝
軸向
包裝
帶卷 (TR)
