MUR180E, MUR1100E

MUR1100E is a Preferred Device

SWITCHMODE鈩?/div>

Power Rectifiers

Ultrafast 鈥淓鈥?Series with High Reverse

Energy Capability

. . . designed for use in switching power supplies, inverters and as

free wheeling diodes, these state鈥搊f鈥搕he鈥揳rt devices have the

following features:

http://onsemi.com

鈥?/div>

10 mjoules Avalanche Energy Guaranteed

鈥?/div>

Excellent Protection Against Voltage Transients in Switching

鈥?/div>

Inductive Load Circuits

Ultrafast 75 Nanosecond Recovery Time

175擄C Operating Junction Temperature

Low Forward Voltage

Low Leakage Current

High Temperature Glass Passivated Junction

Reverse Voltage to 1000 Volts

ULTRAFAST

RECTIFIERS

1.0 AMPERES

800鈥?000 VOLTS

Mechanical Characteristics:

鈥?/div>

Case: Epoxy, Molded

鈥?/div>

Weight: 0.4 gram (approximately)

鈥?/div>

Finish: All External Surfaces Corrosion Resistant and Terminal

鈥?/div>

Leads are Readily Solderable

Lead and Mounting Surface Temperature for Soldering Purposes:

220擄C Max. for 10 Seconds, 1/16鈥?from case

Shipped in plastic bags, 1000 per bag

Available Tape and Reeled, 5000 per reel, by adding a 鈥淩L鈥欌€?suffix to

the part number

Polarity: Cathode Indicated by Polarity Band

Marking: MUR180E, MUR1100E

AXIAL LEAD

CASE 059鈥?4

PLASTIC

MARKING DIAGRAM

MUR1x0E

MAXIMUM RATINGS

Rating

Peak Repetitive Reverse Voltage

Working Peak Reverse Voltage

DC Blocking Voltage

MUR180E

MUR1100E

Average Rectified Forward Current

(Note 1.) (Square Wave Mounting

Method #3 Per Note 3.)

Non-Repetitive Peak Surge Current

(Surge applied at rated load conditions,

halfwave, single phase, 60 Hz)

Operating Junction Temperature and

Storage Temperature Range

Symbol

RRM

RWM

F(AV)

Value

Unit

MUR1x0E = Device Code

= 8 or 10

ORDERING INFORMATION

800

1000

1.0 @

= 95擄C

Device

MUR180E

MUR180ERL

MUR1100E

MUR1100ERL

Package

Axial Lead

Shipping

1000 Units/Bag

5000/Tape & Reel

1000 Units/Bag

5000/Tape & Reel

FSM

, T

stg

鈥?5 to

+175

擄C

Preferred

devices are recommended choices for future use

and best overall value.

1. Pulse Test: Pulse Width = 300

碌s,

Duty Cycle

鈮?/div>

2.0%.

漏

Semiconductor Components Industries, LLC, 2000

October, 2000 鈥?Rev. 0

Publication Order Number:

MUR180E/D
