MUN5330DW1T1 Datasheet

  • MUN5330DW1T1

  • Dual Bias Resistor Transistors

  • 310.60KB

  • 16頁

  • MOTOROLA   MOTOROLA

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

MOTOROLA
SEMICONDUCTOR TECHNICAL DATA
Order this document
by MUN5311DW1T1/D
Dual Bias Resistor Transistors
NPN and PNP Silicon Surface Mount Transistors
with Monolithic Bias Resistor Network
The BRT (Bias Resistor Transistor) contains a single transistor with a
monolithic bias network consisting of two resistors; a series base resistor and a
base鈥揺mitter resistor. These digital transistors are designed to replace a single
device and its external resistor bias network. The BRT eliminates these
individual components by integrating them into a single device. In the
MUN5311DW1T1 series, two complementary BRT devices are housed in the
SOT鈥?63 package which is ideal for low power surface mount applications
where board space is at a premium.
鈥?/div>
Simplifies Circuit Design
鈥?/div>
Reduces Board Space
鈥?/div>
Reduces Component Count
鈥?/div>
Available in 8 mm, 7 inch/3000 Unit Tape and Reel.
MUN5311DW1T1
SERIES
Motorola Preferred Devices
6
5
4
1
2
3
CASE 419B鈥?1, STYLE 1
SOT鈥?63
(3)
R1
Q1
(2)
R2
(1)
Q2
R2
(4)
(5)
R1
(6)
MAXIMUM RATINGS
(TA = 25擄C unless otherwise noted, common for Q1 and Q2, 鈥?minus sign for Q2 (PNP) omitted)
Rating
Collector-Base Voltage
Collector-Emitter Voltage
Collector Current
Symbol
VCBO
VCEO
IC
R
胃JA
TJ, Tstg
PD
Marking
11
12
13
14
15
16
30
31
32
33
34
35
R1 (K)
10
22
47
10
10
4.7
1.0
2.2
4.7
4.7
22
2.2
Value
50
50
100
Unit
Vdc
Vdc
mAdc
擄C/W
擄C
mW
THERMAL CHARACTERISTICS
Thermal Resistance 鈥?Junction-to-Ambient (surface mounted)
Operating and Storage Temperature Range
Total Package Dissipation @ TA = 25擄C(1)
833
鈥?65 to +150
*150
DEVICE MARKING AND RESISTOR VALUES: MUN5311DW1T1 SERIES
Device
MUN5311DW1T1
MUN5312DW1T1
MUN5313DW1T1
MUN5314DW1T1
MUN5315DW1T1(2)
MUN5316DW1T1(2)
MUN5330DW1T1(2)
MUN5331DW1T1(2)
MUN5332DW1T1(2)
MUN5333DW1T1(2)
MUN5334DW1T1(2)
MUN5335DW1T1(2)
R2 (K)
10
22
47
47
鈭?/div>
鈭?/div>
1.0
2.2
4.7
47
47
47
1. Device mounted on a FR-4 glass epoxy printed circuit board using the minimum recommended footprint.
2. New resistor combinations. Updated curves to follow in subsequent data sheets.
Thermal Clad is a trademark of the Bergquist Company
Preferred
devices are Motorola recommended choices for future use and best overall value.
REV 3
Motorola Small鈥揝ignal Transistors, FETs and Diodes Device Data
漏
Motorola, Inc. 1997
1

MUN5330DW1T1 產品屬性

  • ON Semiconductor

  • Transistors Switching (Resistor Biased)

  • Dual

  • NPN/PNP

  • 1 KOhms

  • 1

  • SMD/SMT

  • SC-88-6

  • 50 V

  • 0.1 A

  • 100 mA

  • 187 mW

  • + 150 C

  • Reel

  • - 55 C

  • 3000
