700nm Ultra Bright Emitter
MT85F-UR
pplications
Applications -
鈥?Fiber Optics
鈥?Bar Code Scanning
eatur
tures
Features -
鈥?Visible Light Emiter
鈥?Excellent Optical/Mechanical Axis Alignment
鈥?Designed to Interface With External Optics
RATINGS (Ta
MAXIMUM RATINGS (Ta = 25擄C)
CHARACTERISTIC
SYMBOL
RATING
UNIT
Forward Current (DC)
Forward Current (Pulse)*
Reverse Voltage
Power Dissapation
Operating Temperature
Storage Temperature
Soldering Temperature**
I
F
I
FP
V
R
P
D
T
opr
T
stg
T
j
50
0.5
3
120
-20~80
-30~100
260
mA
A
V
mW
擄C
擄C
潞C
1. Anode
Weight: 0.37 g (TYP.)
2. Cathode
Unit: mm
OPTO-ELECTRICAL CHARACTERISTICS (Ta
OPTO-ELECTRICAL CHARACTERISTICS (Ta = 25擄C)
CHARACTERISTIC
Power Output
Forward Voltage
Reverse Current
Peak Wavelength
Spectral Line Half Width
Switching Speed (10 ~ 90%)
Half Intensity Beam Angle
SYMBOL
PO
V
F
I
R
位
p
鈭單?/div>
T
r
T
f
胃
TEST CONDITION
IF = 20mA
IF = 20mA
VR = 3V
IF = 20mA
IF = 20mA
IFP = 50 mA
鈥?/div>
MIN.
1.0
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
TYP.
2.0
1.85
鈥?/div>
700
25
80
60
鹵65
MAX.
鈥?/div>
2.2
10
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
UNIT
mW
V
碌A(chǔ)
nm
nm
nS
擄
* Pulse Width = 10 碌S, duty = 0.1%
** Time: 5 sec Max. Position: Up to 2 mm from the body
marktech
optoelectronics
For up-to-date product info visit our web site at www.marktechopto.com
120 Broadway 鈥?Menands, New York 12204
Toll Free:
(800) 98-4LEDS
鈥?Fax: (518) 432-7454
All specifications subject to change.
494
