MSM7702-01 Datasheet

  • MSM7702-01

  • Single Rail CODEC

  • OKI

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

E2U0018-28-81
隆 Semiconductor
MSM7702-01/02/03
隆 Semiconductor
Single Rail CODEC
This version: Aug. 1998
MSM7702-01/02/03
Previous version: Nov. 1996
GENERAL DESCRIPTION
The MSM7702 is a single-channel CODEC CMOS IC for voice signals ranging from 300 to 3400
Hz with filters for A/D and D/A conversion.
Designed especially for a single-power supply and low-power applications, the device is
optimized for telephone terminals in digital wireless systems or ISDN systems.
The MSM7702 utilizes low-voltage operational amplifiers (Op-amps) to provide low-power
consumption.
The device uses the same transmission clocks as those used in the MSM7508B and MSM7509B.
The analog output signal can directly drive a piezoelectric type handset receiver.
FEATURES
鈥?Single power supply: +2.7 V to +3.8 V
鈥?Low power consumption
Operating mode:
15 mW Typ.
V
DD
= 3 V
Power save mode:
3.6 mW Typ.
V
DD
= 3 V
Power down mode:
0.05 mW Typ.
V
DD
= 3 V
鈥?ITU-T Companding law
MSM7702-01:
m/A-law
pin selectable
MSM7702-02:
m-law
MSM7702-03: A-law
鈥?Built-in PLL eliminates a master clock
鈥?Serial data rate: 64/128/256/512/1024/2048 kHz
96/192/384/768/1536/1544/200 kHz
鈥?Adjustable transmit gain
鈥?Built-in reference voltage supply
鈥?Analog output can directly drive a load equivalent to 1.2 kW
鈥?Pin-for-pin compatible with the MSM7578 and MSM7579
鈥?Package options:
24-pin plastic SOP (SOP24-P-430-1.27-K)
(Product name : MSM7702-01GS-K)
(Product name : MSM7702-02GS-K)
(Product name : MSM7702-03GS-K)
20-pin plastic SSOP (SSOP20-P-250-0.95-K) (Product name : MSM7702-01MS-K)
(Product name : MSM7702-02MS-K)
(Product name : MSM7702-03MS-K)
1/17
