MSK3013 Datasheet

  • MSK3013

  • QUAD N-CHANNEL MOSFET POWER MODULE

  • 227.21KB

  • 5頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

ISO-9001 CERTIFIED BY DSCC
M.S.KENNEDY CORP.
QUAD N-CHANNEL
MOSFET POWER MODULE
3013
(315) 701-6751
4707 Dey Road Liverpool, N.Y. 13088
FEATURES:
鈥?/div>
Pin Compatible with MPM3013
鈥?/div>
QUAD Independent N - Channel MOSFETS
鈥?/div>
Isolated Package for Direct Heat Sinking, Excellent Thermal Conductivity
鈥?/div>
Avalanche Rated Devices
鈥?/div>
55 Volt, 25 Amp Rated
鈥?/div>
Low RDS (ON) - 0.022鈩?For Each Die
DESCRIPTION:
The MSK 3013 is a QUAD N-Channel power circuit packaged in a space efficient isolated ceramic tab power SIP
package. The MSK 3013 consists of four totally isolated N-Channel MOSFETs. The MSK 3013 uses M.S.Kennedy's
proven power hybrid technology to bring a cost effective high performance circuit for use in today's sophisticated
servo motor and disk drive systems. The MSK 3013 is a replacement for the MPM3013 with only minor differences
in specifications.
EQUIVALENT SCHEMATIC
TYPICAL APPLICATIONS
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Stepper Motor Servo Control
Disk Drive Head Control
X-Y Table Control
Az-El Antenna Control
Various Switching Applications
1
PIN-OUT INFORMATION
1
2
3
4
5
6
Q1
Q1
Q1
Q2
Q2
Q2
Gate
Source
Drain
Gate
Source
Drain
7
8
9
10
11
12
Q3
Q3
Q3
Q4
Q4
Q4
Gate
Source
Drain
Gate
Drain
Source
Rev. B 7/00
