ISO-9001 CERTIFIED BY DESC

M.S.KENNEDY CORP.

4707 Dey Road Liverpool, N.Y. 13088

ULTRA HIGH VOLTAGE

HIGH SPEED

DIFFERENTIAL OP-AMP

130

(315) 701-6751

FEATURES:

Wide Supply Voltage Range 15V to 400V

Fast Slew Rate - 300 V/碌S Typ.

FET Input - Accurate DC Specifications

Electrically Isolated Case

Low Cost Innovative Packaging

Very Low Quiescent Current - 6mA Typ.

Output Current to 鹵200mA

Adjustable Current Limit

DESCRIPTION:

The MSK 130 is a high speed, high voltage differential amplifier designed for output currents up to 鹵200mA.

Since the MSK 130 utilizes external compensation, it exhibits wide bandwidth and greater stability over a wide gain

range. High frequency, high voltage instrumentation circuits and electrostatic transducers are just a sample of the

applications that the MSK 130 is well suited for. The device is packaged in a 10 pin insulated ceramic SIP with holes

for direct heat sink attachment.

EQUIVALENT SCHEMATIC

TYPICAL APPLICATIONS

Ultra-High Voltage Supplies

FET Input Instrumentation Amplifiers

Electrostatic Deflection

Electrostatic Transducers

Piezo Transducer Excitation

1

PIN-OUT INFORMATION

1

2

3

4

5

-Input

+Input

No Connection

No Connection

-Vcc

10

9

8

7

6

Output

Comp2

Comp1

Isense

+Vcc

Rev. B 7/00
