MOTOROLA
SEMICONDUCTOR TECHNICAL DATA
Order this document
by MRFIC2001/D
The MRFIC Line
900 MHz Downconverter
(LNA/Mixer)
The MRFIC2001 is an integrated downconverter designed for receivers
operating in the 800 MHz to 1.0 GHz frequency range. The design utilizes
Motorola鈥檚 advanced MOSAIC 3 silicon bipolar RF process to yield superior
performance in a cost effective monolithic device. Applications for the
MRFIC2001 include CT-1 and CT-2 cordless telephones, remote controls,
video and audio short range links, low cost cellular radios, and ISM band
receivers. A power down control is provided to minimize current drain with
minimum recovery/turn-on time.
鈥?/div>
Conversion Gain = 23 dB (Typ)
鈥?/div>
Supply Current = 4.7 mA (Typ)
鈥?/div>
Power Down Supply Current = 2.0
碌A(chǔ)
(Max)
鈥?/div>
Low LO Drive = 鈥?0 dBm (Typ)
鈥?/div>
LO Impedance Insensitive to Power Down
鈥?/div>
No Image Filtering Required
鈥?/div>
No Matching Required for RF IN Port
鈥?/div>
All Ports are Single Ended
鈥?/div>
Order MRFIC2001R2 for Tape and Reel.
R2 suffix = 2,500 Units per 12 mm, 13 inch Reel.
鈥?/div>
Device Marking = M2001
MRFIC2001
900 MHz
DOWNCONVERTER
LNA/MIXER
SILICON MONOLITHIC
INTEGRATED CIRCUIT
CASE 751-05
(SO-8)
ABSOLUTE MAXIMUM RATINGS
(TA = 25擄C unless otherwise noted)
Rating
Supply Voltage
Control Voltage
Input Power, RF and LO Ports
Operating Ambient Temperature
Storage Temperature
Symbol
VCC
ENABLE
PRF, PLO
TA
Tstg
Value
5.5
5.0
+10
鈥?35 to + 85
鈥?65 to +150
Unit
Vdc
Vdc
dBm
擄C
擄C
RF IN
1
LNA
8
ENABLE
GND
2
7
VCC
GND
3
6
GND
LO IN
4
5
IF OUT/VCC
Pin Connections and Functional Block Diagram
REV 2
漏
MOTOROLA RF DEVICE DATA
Motorola, Inc. 1994
MRFIC2001
1
