MP7613 Datasheet

  • MP7613

  • Octal 12-Bit DAC Array D/A Converter with Output Amplifier a...

  • 16頁

  • EXAR   EXAR

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

MP7613
Octal 12-Bit DAC Array
TM
D/A Converter with Output Amplifier
and Parallel Data/Address
碌P
Control Logic
FEATURES
鈥?/div>
Eight Independent Channel 12-Bit DACs with
Output Amplifiers
鈥?/div>
Low Power 320 mW (typ.)
鈥?/div>
Parallel Digital Data and Address Port
鈥?/div>
Double Buffered Data Interface
鈥?/div>
Readback of DAC Latches
鈥?/div>
Zero Volt Output Preset (Data = 10 .. 00)
鈥?/div>
12-Bit Resolution, 11-Bit Accuracy
鈥?/div>
Extremely Well Matched DACs
鈥?/div>
Extremely Low Analog Ground Current (<60碌A(chǔ)/Channel)
鈥?/div>
+10 V Output Swing with +11.4 V Supplies
鈥?/div>
Rugged Construction 鈥?Latch-Up Proof
鈥?/div>
Serial Version: MP7612
APPLICATIONS
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Data Acquisition Systems
ATE
Process Control
Self-Diagnostic Systems
Logic Analyzers
Digital Storage Scopes
PC Based Controller/DAS
GENERAL DESCRIPTION
The MP7613 provides eight independent 12-bit resolution
Digital-to-Analog Converters with voltage output amplifiers and
a parallel digital address and data port.
Built on using an advanced linear BiCMOS, these devices of-
fer rugged solutions that are latch-up free, and take advantage
of EXAR鈥檚 patented thin-film resistor process which exhibits ex-
cellent long term stability and reliability.
A standard
碌
-processor and TTL/CMOS compatible 12-bit in-
put data port loads the data into the pre-selected DACS.
This device can easily be interfaced to a data bus, and digital
readback of each channel is available.
Typical DAC matching is 0.7 LSB across all codes. Accuracy
of +0.75 LSB for DNL and +1 LSB for INL is achieved for B grade
versions. The output amplifier is capable of sinking and sourc-
ing 5mA, and the output voltage settles to 12-bits in less than
30
碌
s (typ.).
SIMPLIFIED BLOCK DIAGRAM
RB0
12
V
RP
D
Q
LAT0B
XR XE
DAC0
DB0 - DB11
12
Bus
I/O
12
D
Q
LAT0A
XR XE
XE0
+
鈥?/div>
VO0
V
RN
A0 - A2
LD1
RD
CS
R1
R2
LD2
3
8
RB7
XE0 - XE7
RB0 - RB7
D
Q
LAT7A
XR XE
XE7
D
Q
LAT7B
XR XE
12
Control
Logic
8
V
RP
DAC7
V
RN
+
鈥?/div>
VO7
V
RP
V
RP
V
EE
V
EE
V
CC
V
CC
AGND
AGND V
REF
DGND DV
DD
鈥?/div>
+
V
RN
V
REFN
Rev. 2.00
1
