MP04---590

MP04---590

Dual Thyristor, Thyristor/Diode Module

Replaces April 2001 version, DS5371-2.2

DS5371-3.1 October 2001

FEATURES

s

s

s

s

s

s

Dual Device Module

Electrically Isolated Package

Pressure Contact Construction

International Standard Footprint

Alumina (Non Toxic) Isolation Medium

Integral Water Cooled Heatsink

KEY PARAMETERS

V

DRM

I

T(AV)

I

TSM(per arm)

V

isol

1800V

595A

16800A

3000V

Code

HBT

Circuit

APPLICATIONS

s

s

s

s

HBP

HBN

Fig.1 Circuit diagrams

Motor Control

Controlled Rectifier Bridges

Heater Control

AC Phase Control

VOLTAGE RATINGS

Type Number

Repetitive Peak

Voltages

V

DRM

V

RRM

V

1800

1600

1400

Conditions

MP04---590-18

MP04---590-16

MP04---590-14

T

vj

= 0藲 to 125藲C,

I

DRM

= I

RRM

= 50mA

V

DSM

= V

RSM

=

V

DRM

= V

RRM

+ 100V

respectively

Lower voltage grades available.

ORDERING INFORMATION

Order As:

MP04HBT590-18

or

MP04HBT-16

or

MP04HBT14

MP04HBP590-18

or

MP04HBP-16

or

MP04HBP14

MP04HBN590-18

or

MP04HBN-16

or

MP04HBN14

Module type code: MP04.

For further information see Package Details.

Fig. 2 Electrical connections - (not to scale)

Note: When ordering, please use the whole part number.

1/10

www.dynexsemi.com
