Surface Mount, Miniature
Voltage Controlled Oscillator
Linear Tuning
1766 to 1826 MHz
Features
!
EW
N
MOS-1826PV
鈥?small package, .375X.375 inch
鈥?wide modulation bandwidth, 10,000 kHz typ.
Applications
CASE STYLE: CZ682
鈥?DCS/GSM
Electrical Specifications
FREQ.
(MHz)
POWER TUNING
OUTPUT VOLTAGE
(dBm)
Typ.
2
th
PHASE NOISE
dBc/Hz SSB at offset
frequencies:
Typ.
1 MHz
-142
PULLING PUSHING TUNING HARMONICS*
3 dB
pk-pk
(MHz/V) SENSI-
(dBc)
MODULATION
@ 12 dBr
TIVITY
BANDWIDTH
(MHz)
(MHz/V)
(kHz)
Typ.
8
Typ.
1.0
Typ.
21-35
Typ.
-28
Max.
-15
Typ.
10,000
POWER SUPPLY
Current
(mA)
Max.
25
PRICE
$
Qty.
(5-49)
19.95
Min. Max.
1766 1826
Min. Max. 1 kHz 10 kHz 100 kHz
0.5
5
-75
-101
-122
Voltage
(V)
5
* specified to 4 harmonic
Maximum Ratings
Operating Temperature
Storage Temperature
Absolute Max. Supply Voltage (Vcc)
Absolute Max. Tuning Voltage (Vtune)
All specifications: 50 ohm system
-55擄C to 85擄C
-55擄C to 100擄C
+6V
+6V
Outline Drawing
Pin Connections
PORT
RF OUT
V-CC
V-TUNE
GND EXT.
5
3
1
all others
Outline Dimensions (
inch
)
mm
A
.375
9.52
K
.193
4.90
B
.375
9.52
C
.131
3.33
D
.188
4.78
N
.039
0.99
E
.035
0.89
P
.154
3.91
F
.033
0.84
Q
.060
1.52
G
.154
3.91
R
.368
9.35
H
J
.040
.446
1.02 11.33
wt.
grams
.60
REV. A
M78157
EDR-5265/2
MOS-1826PV
RVN/TD/CP
010829
L
M
.060
.446
1.52 11.33
