MN101E01K, MN101E01L, MN101E01M
Type
ROM (脳 8-bit)
脳
External memory can be expanded
MN101E01K (under development)
256 K
MN101E01L (under development)
320 K
MN101E01M (under development)
384 K
RAM (脳 8-bit)
脳
External memory can be expanded
10 K
14 K
24 K
Package
Minimum Instruction
Execution Time
Standard:
QFP100-P-1818B
*Lead-free
0.0625
碌s
(at 3.0 V to 3.6 V, 32 MHz)
0.238
碌s
(at 3.0 V to 3.6 V, 8.39 MHz)
125
碌s
(at 3.0 V to 3.6 V, 32 kHz)
Double speed: 0.10
碌s
(at 3.0 V to 3.6 V, 10 MHz)
0.25
碌s
(at 3.0 V to 3.6 V, 4 MHz)
62.5
碌s
(at 3.0 V to 3.6 V, 32 kHz)
鈥?RESET 鈥?Watchdog 鈥?External 0 鈥?External 1 鈥?External 2 鈥?External 3 鈥?External 4 鈥?External 5 鈥?Timer 0
鈥?Timer 1 鈥?Timer 2 鈥?Timer 3 鈥?Timer 4 鈥?Timer 5 鈥?Timer 6 鈥?Timer 7 (2 systems) 鈥?Time base 鈥?Serial 0
鈥?Serial 1 鈥?Serial 2 鈥?Serial 3 鈥?Serial 4 鈥?Automatic transfer finish 鈥?A/D conversion finish 鈥?Key interrupts (8 lines)
Timer counter 0 : 8-bit
脳
1
(square-wave/8-bit PWM output, event count, generation of remote control carrier, pulse width measurement)
Clock source 路路路路路路路路路路路路路路路路路路路路路 1/2, 1/4 of system clock frequency; 1/1, 1/4, 1/16, 1/32, 1/64 of OSC oscillation
clock frequency; 1/1 of XI oscillation clock frequency; external clock input
Interrupt source 路路路路路路路路路路路路路路路路 coincidence with compare register 0
Timer counter 1 : 8-bit
脳
1 (square-wave output, event count, synchronous output event)
Clock source 路路路路路路路路路路路路路路路路路路路路路 1/2, 1/8 of system clock frequency; 1/1, 1/4, 1/16, 1/64, 1/128 of OSC oscillation
clock frequency; 1/1 of XI oscillation clock frequency; external clock input
Interrupt source 路路路路路路路路路路路路路路路路 coincidence with compare register 1
Timer counter 0, 1 can be cascade-connected.
Timer counter 2 : 8-bit
脳
1 (square-wave/8-bit PWM output, event count, synchronous output event, pulse width
measurement, serial baud rate timer)
Clock source 路路路路路路路路路路路路路路路路路路路路路 1/2, 1/4 of system clock frequency; 1/1, 1/4, 1/16, 1/32, 1/64 of OSC oscillation
clock frequency; 1/1 of XI oscillation clock frequency; external clock input
Interrupt source 路路路路路路路路路路路路路路路路 coincidence with compare register 2
Timer counter 3 : 8-bit
脳
1 (square-wave output, event count, generation of remote control carrier, serial baud rate timer)
Clock source 路路路路路路路路路路路路路路路路路路路路路 1/2, 1/8 of system clock frequency; 1/1, 1/4, 1/16, 1/64, 1/128 of OSC
oscillation clock frequency; 1/1 of XI oscillation clock frequency; external
clock input
Interrupt source 路路路路路路路路路路路路路路路路 coincidence with compare register 3
Timer counter 2, 3 can be cascade-connected.
Timer counter 4 : 8-bit
脳
1
(square-wave/8-bit PWM output, event count, pulse width measurement, serial baud rate timer)
Clock source 路路路路路路路路路路路路路路路路路路路路路 1/2, 1/4 of system clock frequency; 1/1, 1/4, 1/16, 1/32, 1/64 of OSC oscillation
clock frequency; 1/1 of XI oscillation clock frequency; external clock input
frequency
Interrupt source 路路路路路路路路路路路路路路路路 coincidence with compare register 4
Timer counter 5 : 8-bit
脳
1 (square-wave output, event count, serial baud rate timer)
Clock source 路路路路路路路路路路路路路路路路路路路路路 1/2, 1/4 of system clock frequency; 1/1, 1/4, 1/16, 1/64, 1/128 of OSC
oscillation clock frequency; 1/1 of XI oscillation clock frequency; external
clock input
Interrupt source 路路路路路路路路路路路路路路路路 coincidence with compare register 5
Timer counter 4, 5 can be cascade-connected.
Interrupts
Timer Counter
1
MAD00034CEM
1
2
3
4
5
