Interrupts
RESET, Watchdog, External
0
to
5,
Timer
0
to
8,
Time base, Serial
0
reception, Serial
0
transmission, Serial
1
reception, Serial
1
transmission, Serial
2,
Serial
3,
Serial
4
reception, Serial
4
transmission, Automatic transfer 鏗乶ish, A/D conversion 鏗乶ish, Key
interrupts (12 lines)
Timer counter
0
:
8-bit
脳
1
(square-wave/8-bit PWM output, event count, pulse width measurement, serial clock output, real-time output control,
generation of remote control carrier)
Clock source................
1/2, 1/4
of system clock frequency;
1/1, 1/4, 1/16, 1/32, 1/64
of OSC oscillation clock frequency;
1/1
of
XI oscillation clock frequency; external clock input
Interrupt source ........... coincidence with compare register
0
Timer counter
1
:
8-bit
脳
1
(square-wave output, event count, synchronous output event, serial clock output)
Clock source................
1/2, 1/8
of system clock frequency;
1/1, 1/4, 1/16, 1/64, 1/128
of OSC oscillation clock frequency;
1/1
of
XI oscillation clock frequency; external clock input
Interrupt source ........... coincidence with compare register
1
Timer counter
0, 1
can be cascade-connected.
飩?/div>
Timer Counter
Timer counter
2
:
8-bit
脳
1
(square-wave output, PWM output, event count, pulse width measurement, synchronous timer, serial clock output)
Clock source................
1/2, 1/4
of system clock frequency;
1/1, 1/4, 1/16, 1/32, 1/64
of OSC oscillation clock frequency;
1/1
of
XI oscillation clock frequency; external clock input
Interrupt source ........... coincidence with compare register
2
Timer counter
0, 1, 2
can be cascade-connected.
Timer counter
3
:
8-bit
脳
1
(square-wave output, event count, serial clock output)
Clock source................
1/2, 1/8
of system clock frequency;
1/1, 1/4, 1/16, 1/64, 1/128
of OSC oscillation clock frequency;
1/1
of
XI oscillation clock frequency; external clock input
Interrupt source ........... coincidence with compare register
3
Timer counter
2, 3
can be cascade-connected.
Timer counter
0, 1, 2, 3
can be cascade-connected.
Timer counter
4
:
8-bit
脳
1
(square-wave/8-bit PWM output, event count, pulse width measurement, real-time output control, serial clock output)
Clock source................
1/2, 1/4
of system clock frequency;
1/1, 1/4, 1/16, 1/32, 1/64
of OSC oscillation clock frequency;
1/1
of
XI oscillation clock frequency;
1/1
of external clock input frequency
Interrupt source ........... coincidence with compare register
4
Timer counter
5
:
8-bit
脳
1
(square-wave/8-bit PWM output, event count, pulse width measurement, serial clock output)
Clock source................
1/2, 1/8
of system clock frequency;
1/1, 1/4, 1/16, 1/64, 1/128
of OSC oscillation clock frequency;
1/1
of
XI oscillation clock frequency; external clock input
Interrupt source ........... coincidence with compare register
5
Timer counter
4, 5
can be cascade-connected.
