MM54HC05 MM74HC05 Hex Inverter (Open Drain)
January 1988
MM54HC05 MM74HC05
Hex Inverter (Open Drain)
General Description
The MM54HC05 MM74HC05 are logic functions fabricated
by using advanced silicon-gate CMOS technology which
provides the inherent benefits of CMOS low quiescent
power and wide power supply range These devices are
also functionally and pin-out compatible with standard
DM54LS DM74LS logic families
The MM54HC05
MM74HC05 open drain Hex Inverter requires the addition of
an external resistor to perform a wire-NOR function
All inputs are protected from static discharge damage by
internal diodes to V
CC
and ground
Features
Y
Y
Y
Y
Open drain for wire-NOR function
Fanout of 10 LS-TTL loads
Typical propagation delays
t
PZL
(with 1 kX resistor) 8 ns
t
PLZ
(with 1 kX resistor) 13 ns
Low input current 1
mA
maximum
Connection Diagram
Dual-In-Line Package
TL F 9388 鈥?1
Top View
Order Number MM54HC05 or MM74HC05
Logic Diagram
Typical Application
TL F 9388 鈥?2
TL F 9388 鈥?3
Note
Can be extended to more than 2 inputs
C
1995 National Semiconductor Corporation
TL F 9388
RRD-B30M105 Printed in U S A
