MITSUMI

CMOS Regulator MM303X Series

CMOS Regulator

Monolithic IC MM303X Series

Outline

This IC is a voltage regulator IC developed using the CMOS process. Super low consumption current of

1.5 碌A(chǔ) typ. (MM303X) (when not loaded) has been achieved through the use of the CMOS process. Also, the

output voltage has a high accuracy of 鹵2%.

Features

1. Super low consumption current

2. Super low consumption current (when off)

3. High precision output voltage

4. Input/output voltage difference

5. Good input stability

6. Built-in short-circuit restriction circuit

7. Wide operating temperature range

8. Output voltage

1.5碌A(chǔ) typ. (when not loaded, excluding the CE terminal current)

0.1碌A(chǔ) typ.

鹵2%

40mV typ. (Io=1mA MM3033A)

0.05%/V typ.

60mA typ.

-30~+85擄C

1.7~5.5V (0.1V step)

Package

SC-82AB

Applications

1. Devices that use batteries

2. Portable communications devices

3. Household electronics products

Block Diagram
