MITSUMI

Low-Output Voltage Low-Saturation Three-Pin Regulator MM1270

Low-Output Voltage Low-Saturation Three-Pin Regulator

Monolithic IC MM1270

Outline

MM1270 is targeted at the one-battery output voltage market, and is a compact low input/output voltage

differential stable power supply with ultra-low current consumption.

Features

1. Input voltage

2. Input/output voltage differential

3. Input current for no load

4. Output voltage

5. Current limiter circuit included

6. On/Off logic

10V max.

0.05V typ.

15碌A(chǔ) typ.

1.08V, 1.03V typ.

CE pin

LOW

HIGH

Output

OFF

ON

Package

SOT-25A (MM1270CN, MM1270ZN)

Applications

1. Pagers

2. Headphone stereos

3. Portable equipment

Pin Assignment

1

5

4

2

3

1

2

3

4

5

SOT-25A

V

OUT

GND

GND

CE

V

IN

next
