General Purpose Relay

Exceptionally reliable general purpose

relay

Long life (minimum 100,000 electrical

operations) assured by silver contacts

Built-in operation indicator (mechanical,

LED), diode surge suppression, Varistor

surge suppression

The contact operation can be easily

checked by mechanical indicator and/or

push-to-test button options

Conforms to CENELEC standards

VDE approved versions available

MK

Ordering Information

To Order: Select the part number and add the desired coil voltage rating (e.g., MK3P5-S-

).

Part number

Type

Standard

LED indicator

LED indicator and diode

LED indicator and varistor

Diode

Varistor

DC

AC

DC

AC

Terminal

Plug-in

Coil

AC/DC

Contact form

DPDT

3PDT

DPDT

3PDT

DPDT

3PDT

DPDT

3PDT

DPDT

3PDT

DPDT

3PDT

Mechanical

indicator

MK2P-I

MK3P-5-I

MK2PN-I

MK3PN-5-I

MK2PND-I

MK3PND-5-I

MK2PNV-I

MK3PNV-5-I

MK2PD-I

MK3PD-5-I

MK2PV-I

MK3PV-5-I

Mechanical indicator

& push-to-test button

MK2P-S

MK3P-5-S

MK2PN-S

MK3PN-5-S

MK2PND-S

MK3PND-5-S

MK2PNV-S

MK3PNV-5-S

MK2PD-S

MK3PD-5-S

MK2PV-S

MK3PV-5-S

Note: 1. Reverse polarity versions available on DC coil types. Consult your OMRON representative for further information.

2. VDE approved versions are available. Consult your OMRON representative for further information.

ACCESSORIES

(Order separately)

To Order: Select the appropriate part numbers for sockets, clips, and mounting tracks (if required) from the available types chart.

Track mounted sockets

Part number

Socket

PF083A-E

PF113A-E

Relay type

SPDT

DPDT

3PDT

Relay hold-down clip

PFC-A1

PFC-A1

Mounting track/end plate

PFP-100N

or

PFP-50N

and

PFP-M

(end plate)

PFP-100N

or

PFP-50N

and

PFP-M

(end plate)
