MIC912
Micrel
MIC912
200MHz Low-Power SOT-23-5 Op Amp
General Description
The MIC912 is a high-speed, unity-gain stable operational
amplifier. It provides a gain-bandwidth product of 200MHz
with a very low, 2.4mA supply current, and features the tiny
SOT-23-5 package.
Supply voltage range is from
鹵2.5V
to
鹵9V,
allowing the
MIC912 to be used in low-voltage circuits or applications
requiring large dynamic range.
The MIC912 is stable driving any capacitative load and
achieves excellent PSRR, making it much easier to use than
most conventional high-speed devices. Low supply voltage ,
low power consumption, and small packing make the MIC912
ideal for portable equipment. The ability to drive capacitative
loads also makes it possible to drive long coaxial cables.
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
200MHz gain bandwidth product
2.4mA supply current
SOT-23-5 package
360V/碌s slew rate
drives any capacitive load
Applications
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Video
Imaging
Ultrasound
Portable equipment
Line drivers
Ordering Information
Part Number
MIC912BM5
Junction Temp. Range
鈥?0擄C to +85擄C
Package
SOT-23-5
Pin Configuration
IN+
3
Functional Pinout
V+ OUT
2
1
IN+
V+ OUT
2
1
Part
Identification
3
A23
4
5
4
5
IN鈥?/div>
V鈥?/div>
IN鈥?/div>
V鈥?/div>
SOT-23-5
SOT-23-5
Pin Description
Pin Number
1
2
3
4
5
Pin Name
OUT
V+
IN+
IN鈥?/div>
V鈥?/div>
Pin Function
Output: Amplifier Output
Positive Supply (Input)
Noninverting Input
Inverting Input
Negative Supply (Input)
Micrel, Inc. 鈥?1849 Fortune Drive 鈥?San Jose, CA 95131 鈥?USA 鈥?tel + 1 (408) 944-0800 鈥?fax + 1 (408) 944-0970 鈥?http://www.micrel.com
June 2000
1
MIC912
