The MIC6251 and MIC6252 are IttyBitty鈩?GainBlock鈩?/div>
amplifiers for use as follows:
MIC6251 ................................ +2, +1, 鈥? gain amplifier
MIC6252 .................................. +0.5, +1 gain amplifier;
average value amplifier
The MIC6251 and MIC6252 amplifiers operate from 4V to
32V. Both can use single or split supplies. These amplifiers
feature internal, well-matched, gain-setting resistors and an
input common-mode range that includes the negative supply
(ground).
The MIC6251/2 is available in the tiny SOT-23-5 surface
mount package.
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
4V to 32V operation
Small footprint package
Internally compensated
2MHz bandwidth
6V/碌s typical slew rate
Short circuit protected
Applications
鈥?Analog building blocks
鈥?Summing amplifier
鈥?Gain block
Ordering Information
Part Number
MIC6251BM5
MIC6252BM5
Marking
A51
A52
Temperature
鈥?0擄C to +85擄C
鈥?0擄C to +85擄C
Range Package
SOT-23-5
SOT-23-5
Functional Configuration
IN+
3
20k
V鈥?/div>
2
OUT
1
20k
20k
20k
20k
4
IN鈥?/div>
5
V+
IN+
3
V鈥?/div>
2
OUT
1
20k
20k
4
IN鈥?/div>
20k
5
V+
MIC6251
MIC6252
Pin Configuration
IN+
3
V鈥?OUT
2
1
Part Number
MIC6251BM5
MIC6252BM5
Identification
A51
A52
4
Axx
5
Part
Identification
IN鈥?/div>
V+
SOT-23-5 (M5)
IttyBitty and GainBlock are a trademarks of Micrel, Inc.
Micrel, Inc. 鈥?1849 Fortune Drive 鈥?San Jose, CA 95131 鈥?USA 鈥?tel + 1 (408) 944-0800 鈥?fax + 1 (408) 944-0970 鈥?http://www.micrel.com
July 1998
1
MIC6251/6252
