MCP1700 Datasheet

  • MCP1700

  • Low Quiescent Current LDO

  • 24頁

  • Microchip   Microchip

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

M
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
1.6 碌A(chǔ) Typical Quiescent Current
Input Operating Voltage Range: 2.3V to 6.0V
Output Voltage Range: 1.2V to 5.0V
250 mA Output Current for output voltages
鈮?/div>
2.5V
200 mA Output Current for output voltages < 2.5V
Low Dropout (LDO) voltage
- 178 mV typical @ 250 mA for V
OUT
= 2.8V
0.4% Typical Output Voltage Tolerance
Standard Output Voltage Options:
- 1.2V, 1.8V, 2.5V, 3.0V, 3.3V, 5.0V
Stable with 1.0 碌F Ceramic Output capacitor
Short-Circuit Protection
Overtemperature Protection
MCP1700
Description
The MCP1700 is a family of CMOS low dropout (LDO)
voltage regulators that can deliver up to 250 mA of
current while consuming only 1.6 碌A(chǔ) of quiescent
current (typical). The input operating range is specified
from 2.3V to 6.0V, making it an ideal choice for two and
three primary cell battery-powered applications, as well
as single cell Li-Ion-powered applications.
The MCP1700 is capable of delivering 250 mA with
only 178 mV of input to output voltage differential
(V
OUT
= 2.8V). The output voltage tolerance of the
MCP1700 is typically 鹵0.4% at +25擄C and 鹵3%
maximum over the operating junction temperature
range of -40擄C to +125擄C.
Output voltages available for the MCP1700 range from
1.2V to 5.0V. The LDO output is stable when using only
1 碌F output capacitance. Ceramic, tantalum or
aluminum electrolytic capacitors can all be used for
input and output. Overcurrent limit and overtemperature
shutdown provide a robust solution for any application.
Package options include the SOT23, SOT89-3 and
TO92.
Low Quiescent Current LDO
Applications
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Battery-powered Devices
Battery-powered Alarm Circuits
Smoke Detectors
CO
2
Detectors
Pagers and Cellular Phones
Smart Battery Packs
Low Quiescent Current Voltage Reference
PDAs
Digital Cameras
Microcontroller Power
Package Types
3-Pin SOT23-A
V
IN
3
MCP1700
1
2
MCP1700
1
2
3
GND V
IN
V
OUT
3-Pin SOT-89
V
IN
3-Pin TO-92
MCP1700
1 2 3
Related Literature
鈥?AN765, 鈥淯sing Microchip鈥檚 Micropower LDOs鈥?
DS00765, Microchip Technology Inc., 2002
鈥?AN766, 鈥淧in-Compatible CMOS Upgrades to
BiPolar LDOs鈥? DS00766,
Microchip Technology Inc., 2002
鈥?AN792, 鈥淎 Method to Determine How Much
Power a SOT23 Can Dissipate in an Application鈥?
DS00792, Microchip Technology Inc., 2001
GND V
OUT
GND V
IN
V
OUT
錚?/div>
2003 Microchip Technology Inc.
DS21826A-page 1
