MC33199 Datasheet

  • MC33199

  • Automotive ISO 9141 Serial Link Driver

  • Motorola   Motorola

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Order this document by MC33199/D
Automotive ISO 9141
Serial Link Driver
The MC33199D is a serial interface circuit used in diagnostic
applications. It is the interface between the microcontroller and the special
K and L Lines of the ISO diagnostic port. The MC33199D has been
designed to meet the 鈥淒iagnosis System ISO 9141鈥?specification.
The device has a bi鈥揹irectional bus K Line driver, fully protected against
short circuits and over temperature. It also includes the L Line receiver,
used during the wake up sequence in the ISO transmission.
The MC33199 has a unique feature which allows transmission baud rate
up to 200 k baud.
MC33199
ISO 9141
SERIAL LINK DRIVER
SEMICONDUCTOR
TECHNICAL DATA
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Electrically Compatible with Specification 鈥淒iagnosis System ISO 9141鈥?/div>
Transmission Speed Up to 200 k Baud
Internal Voltage Reference Generator for Line Comparator Thresholds
TXD, RXD and LO Pins are 5.0 V CMOS Compatible
High Current Capability of DIA Pin (K Line)
Short Circuit Protection for the K Line Input
Over Temperature Shutdown with Hysteresis
Large Operating Range of Driver Supply Voltage
Full Operating Temperature Range
ESD Protected Pins
D SUFFIX
PLASTIC PACKAGE
CASE 751A
(SO鈥?4)
14
1
Simplified Application
VCC
VS
PIN CONNECTIONS
REF鈥揙UT
LO
Reference
Generator
+
C2
鈥?/div>
Protection
L
VCC
REF鈥揑N鈥揕
REF鈥揑N鈥揔
LO
1
2
3
4
5
6
7
14 REF鈥揙UT
13 VS
12 L
11 I1
10 Gnd
9 DIA
8 NC
REF鈥揑N鈥揕
REF鈥揑N鈥揔
RXD
VCC
C1
鈥?/div>
+
I1
Source
I1
RXD
TXD
NC
DIA
Thermal
Shutdown
TXD
Driver
Gnd
Current
Limit
Device
This device contains 94 active transistors.
MC33199D
(Top View)
ORDERING INFORMATION
Operating
Temperature Range
TA = 鈥?40擄 to +125擄C
Package
SO鈥?4
Rev 0
漏
Motorola, Inc. 1996
MOTOROLA ANALOG IC DEVICE DATA
1
