MC100LVEL37
3.3V ECL 1:4
梅1/梅2
Clock
Fanout Buffer
Description
The MC100LVEL37 is a fully differential 1:4 fanout buffer. The
device offers two outputs at
梅1
of the input frequency, and two outputs
at
梅2
of the input frequency. The Low Output鈭扥utput Skew of the
device makes it ideal for distributing 1x and 1/2x frequency
synchronous signals.
The differential inputs have special circuitry which ensures device
stability under open input conditions. When both differential inputs
are left open the CLKn input will pull down to V
EE
, The CLKn input
will bias around V
CC
/2 and the Qn output will go LOW.
Features
http://onsemi.com
鈥?/div>
700 ps Typical Propagation Delays
鈥?/div>
50 ps Maximum Output鈭扥utput Skews
鈥?/div>
ESD Protection: >2 kV Human Body Model,
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
SO鈭?0 WB
DW SUFFIX
CASE 751D
>200 V Machine Model
The 100 Series Contains Temperature Compensation
PECL Mode Operating Range: V
CC
= 3.0 V to 3.8 V
with V
EE
= 0 V
NECL Mode Operating Range: V
CC
= 0 V
with V
EE
=
鈭?.0
V to
鈭?.8
V
Internal Input Pulldown Resistors
Qn Output will Default LOW with Inputs Open or at V
EE
Meets or Exceeds JEDEC Spec EIA/JESD78 IC Latchup Test
Moisture Sensitivity Level 1
For Additional Information, see Application Note AND8003/D
Flammability Rating: UL 94 V鈭? @ 0.125 in,
Oxygen Index 28 to 34
Transistor Count = 256 devices
Pb鈭扚ree Packages are Available*
MARKING DIAGRAM*
20
100LVEL37
AWLYYWWG
1
A
WL
YY
WW
G
= Assembly Location
= Wafer Lot
= Year
= Work Week
= Pb鈭扚ree Package
*For additional marking information, refer to
Application Note AND8002/D.
ORDERING INFORMATION
See detailed ordering and shipping information in the package
dimensions section on page 5 of this data sheet.
*For additional information on our Pb鈭扚ree strategy and soldering details, please
download the ON Semiconductor Soldering and Mounting Techniques
Reference Manual, SOLDERRM/D.
漏
Semiconductor Components Industries, LLC, 2006
November, 2006
鈭?/div>
Rev. 5
1
Publication Order Number:
MC100LVEL37/D
