MAX9382 Evaluation Kit
General Description
The MAX9382 evaluation kit (EV kit) includes the
MAX9382, a high-speed PECL/ECL phase-frequency
detector. The EV kit evaluates the MAX9382, which
compares single-ended reference (R) and VCO (V)
inputs and produces pulse streams on differential up
(U) and down (D) outputs, depending on the input
phase or frequency difference. The EV kit operates up
to 450MHz.
The MAX9382 EV kit is designed with 50鈩?controlled-
impedance traces in a four-layer PC board. The EV kit
can also be used to evaluate the MAX9383.
o
Controlled 50鈩?Microstrip Traces
o
Equal Input Trace Lengths
o
Output Trace Lengths Matched to <2mils
o
Board Frequency: Up to 450MHz
o
PECL/ECL Supply
o
8-Pin SO Package
o
Fully Assembled and Tested
Features
Evaluates: MAX9382/MAX9383
Ordering Information
PART
MAX9382EVKIT
TEMP RANGE
0擄C to +70擄C
IC PACKAGE
8 SO
Note:
To evaluate the MAX9383, request a MAX9383ESA free
sample with the MAX9382EVKIT.
Component List
DESIGNATION
QTY
2
DESCRIPTION
10碌F
鹵10%,
10V tantalum
capacitors (B case)
AVX TAJB106K010R or
Kemet T494B106K010AS
0.1碌F
鹵10%,
16V X7R ceramic
chip capacitors (0603)
Taiyo Yuden EMK107BJ104KA or
Murata GRM39X7R104K016A
0.01碌F
鹵10%,
16V X7R ceramic
capacitors (0402)
Taiyo Yuden EMK105BJ103KW
or
Murata GRM36X7R103K016AD
DESIGNATION
R1, R3
R2, R4
R5鈥揜8
QTY
2
0
4
DESCRIPTION
49.9鈩?/div>
鹵1%
resistors (0402)
Not installed, resistor (0402)
100鈩?/div>
鹵0.1%,
1/4W resistors
(0805)
IRC PFC-W0805R-03-1000-B
SMA edge-mount connectors
Johnson Components
142-0701-801
MAX9382ESA (8-pin SO)
MAX9382 PC board
MAX9382 EV kit data sheet
MAX9382 data sheet
C1, C2
C3, C4
2
R, V, U,
U,
D,
D
U1
None
None
None
6
1
1
1
1
C5, C6
2
Component Suppliers
SUPPLIER
AVX
IRC
Kemet
Murata
Taiyo Yuden
PHONE
843-946-0238
361-992-7900
864-963-6300
770-436-1300
800-348-2496
FAX
843-626-3123
361-992-3377
864-963-6322
770-436-3030
847-925-0899
WEBSITE
www.avxcorp.com
www.irctt.com
www.kemet.com
www.murata.com
www.t-yuden.com
Note:
Please indicate that you are using the MAX9382/MAX9383 when contacting these component suppliers.
