MAX9181 Datasheet

  • MAX9181

  • " Low-Jitter, Low-Noise LVPECL-to-LVDS Level Translator in a...

  • Maxim   Maxim

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

19-2415; Rev 0; 4/02
Low-Jitter, Low-Noise LVPECL-to-LVDS Level
Translator in an SC70 Package
General Description
The MAX9181 is an LVPECL-to-LVDS level translator
that accepts a single LVPECL input and translates it to
a single LVDS output. It is ideal for interfacing between
LVPECL and LVDS interfaces in systems that require
minimum jitter, noise, power, and space.
Ultra-low, 23ps
P-P
added deterministic jitter and
0.6ps
RMS
added random jitter ensure reliable commu-
nication in high-speed links that are highly sensitive to
timing errors, especially those incorporating clock-and-
data recovery, PLLs, serializers, or deserializers. The
MAX9181鈥檚 switching performance guarantees a
400Mbps data rate, but minimizes radiated noise by
guaranteeing 0.5ns minimum output transition time.
The MAX9181 operates from a single 3.3V supply and
consumes only 10mA supply current over a -40擄C to
+85擄C temperature range. It is available in a tiny 6-pin
SC70 package (half the size of a SOT23). Refer to the
MAX9180 data sheet for a low-jitter, low-noise LVDS
repeater in an SC70 package.
o
Tiny SC70 Package
o
Ultra-Low Jitter
23ps
P-P
Added Deterministic Jitter
(2
23
- 1 PRBS)
0.6ps
RMS
Added Random Jitter
o
0.5ns (min) Transition Time Minimizes Radiated
Noise
o
400Mbps Guaranteed Data Rate
o
Low 10mA Supply Current
o
Conforms to ANSI/EIA/TIA-644 LVDS Standard
o
High-Impedance Inputs and Outputs in
Power-Down Mode
Features
MAX9181
Applications
Digital Cross-Connects
Add/Drop Muxes
Network Switches/Routers
Cellular Phone Base Stations
DSLAMs
Multidrop Buses
PART
MAX9181EXT-T
Ordering Information
TEMP RANGE
-40擄C to +85擄C
PIN-
PACKAGE
6 SC70-6
TOP
MARK
ABD
Pin Configuration
Typical Operating Circuit
V
CC
3.3V
OUT- 1
TOP VIEW
MAX9181
6
OUT+
MAX9181
OUT+
IN+
LVPECL
DRIVER
IN-
IN- 3
GND
4
IN+
OUT-
LVDS
SIGNALS
GND 2
5
V
CC
SC70
________________________________________________________________
Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim鈥檚 website at www.maxim-ic.com.
