19-2578; Rev 0; 10/02
Single/Dual LVDS Line Receivers with
鈥淚n-Path鈥?Fail-Safe
General Description
The MAX9171/MAX9172 single/dual low-voltage differential
signaling (LVDS) receivers are designed for high-speed
applications requiring minimum power consumption,
space, and noise. Both devices support switching rates
exceeding 500Mbps while operating from a single 3.3V
supply.
The MAX9171 is a single LVDS receiver and the
MAX9172 is a dual LVDS receiver. Both devices con-
form to the ANSI TIA/EIA-644 LVDS standard and con-
vert LVDS to LVTTL/LVCMOS-compatible outputs. A
fail-safe feature sets the outputs high when the inputs
are undriven and open, terminated, or shorted. The
MAX9171/MAX9172 are available in 8-pin SO packages
and space-saving thin QFN and SOT23 packages.
For lower skew devices, refer to the MAX9111/ MAX9113
data sheet.
o
Input Accepts LVDS and LVPECL
o
In-Path Fail-Safe Circuit
o
Space-Saving 8-Pin QFN and SOT23 Packages
o
Fail-Safe Circuitry Sets Output High for Open,
Undriven Shorted, or Undriven Terminated Output
o
Flow-Through Pinout Simplifies PC Board Layout
o
Guaranteed 500Mbps Data Rate
o
Second Source to DS90LV018A and DS90LV028A
(SO Packages Only)
o
Conforms to ANSI TIA/EIA-644 Standard
o
3.3V Supply Voltage
o
-40擄C to +85擄C Operating Temperature Range
o
Low Power Dissipation
Features
MAX9171/MAX9172
Applications
Multipoint Backplane Interconnect
Laser Printers
Digital Copiers
Cellular Phone Base Stations
LCD Displays
Network Switches/Routers
Clock Distribution
Ordering Information
PART
MAX9171EKA-T
MAX9171ESA
MAX9171ETA*
MAX9172EKA-T
MAX9172ESA
MAX9172ETA*
TEMP RANGE
-40擄C to +85擄C
-40擄C to +85擄C
-40擄C to +85擄C
-40擄C to +85擄C
-40擄C to +85擄C
-40擄C to +85擄C
PIN-
PACKAGE
8 SOT23-8
8 SO
8 Thin QFN
8 SOT23-8
8 SO
8 Thin QFN
TOP
MARK
AALX
鈥?/div>
鈥?/div>
AALY
鈥?/div>
鈥?/div>
*Future
product鈥攃ontact factory for availability.
Pin Configurations
MAX9171
V
CC
GND
OUT
N.C.
MAX9171
MAX9172
MAX9172
IN- 1
IN+ 2
N.C. 3
N.C. 4
8 V
CC
7 OUT
6 N.C.
5 GND
1
2
3
4
8 IN-
7 IN+
6 N.C.
5 N.C.
IN1- 1
IN1+ 2
IN2+ 3
IN2- 4
8 V
CC
7 OUT1
6 OUT2
5 GND
V
CC
1
GND 2
OUT1 3
OUT2 4
8 IN1-
7 IN1+
6 IN2+
5 IN2-
SO/QFN*
SOT23
SO/QFN*
SOT23
________________________________________________________________
Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim鈥檚 website at www.maxim-ic.com.
