MAX9124 Datasheet

  • MAX9124

  • Quad LVDS Line Driver

  • Maxim   Maxim

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

19-1991; Rev 0; 4/01
KIT
ATION
EVALU
BLE
AVAILA
Quad LVDS Line Driver
Features
o
Pin Compatible with DS90LV031A
o
Guaranteed 800Mbps Data Rate
o
250ps Maximum Pulse Skew
o
Conforms to TIA/EIA-644 LVDS Standard
o
Single +3.3V Supply
o
16-Pin TSSOP and SO Packages
General Description
The MAX9124 quad low-voltage differential signaling
(LVDS) line driver is ideal for applications requiring high
data rates, low power, and low noise. The MAX9124 is
guaranteed to transmit data at speeds up to 800Mbps
(400MHz) over controlled impedance media of approxi-
mately 100鈩? The transmission media may be printed
circuit (PC) board traces, backplanes, or cables.
The MAX9124 accepts four LVTTL/LVCMOS input levels
and translates them to LVDS output signals. Moreover,
the MAX9124 is capable of setting all four outputs to a
high-impedance state through two enable inputs, EN and
EN,
thus dropping the device to an ultra-low-power state
of 16mW (typ) during high impedance. The enables are
common to all four transmitters. Outputs conform to the
ANSI TIA/EIA-644 LVDS standard.
The MAX9124 operates from a single +3.3V supply and is
specified for operation from -40擄C to +85擄C. It is available
in 16-pin TSSOP and SO packages. Refer to the MAX9125/
MAX9126 data sheet for quad LVDS line receivers.
MAX9124
Ordering Information
PART
MAX9124EUE
MAX9124ESE
TEMP. RANGE
-40擄C to +85擄C
-40擄C to +85擄C
PIN-PACKAGE
16 TSSOP
16 SO
Applications
Digital Copiers
Laser Printers
Cell Phone Base
Stations
Add/Drop Muxes
Digital Cross-Connects
DSLAMs
Network
Switches/Routers
Backplane
Interconnect
Clock Distribution
Typical Applications Circuit
LVDS SIGNALS
MAX9126
MAX9124
T
X
115鈩?/div>
R
X
Pin Configuration
TOP VIEW
IN1 1
OUT1+ 2
OUT1- 3
EN 4
OUT2- 5
OUT2+ 6
IN2 7
GND 8
16 V
CC
15 IN4
14 OUT4+
LVTTL/LVCMOS
DATA INPUT
T
X
115鈩?/div>
R
X
LVTTL/LVCMOS
DATA OUTPUT
T
X
115鈩?/div>
R
X
MAX9124
13 OUT4-
12 EN
11 OUT3-
10 OUT3+
9
IN3
100鈩?SHIELDED TWISTED CABLE OR MICROSTRIP PC BOARD TRACES
T
X
115鈩?/div>
R
X
TSSOP/SO
* Future product鈥攃ontact factory for availability.
________________________________________________________________
Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim鈥檚 website at www.maxim-ic.com.
