19-2051; Rev 0; 5/01
MAX6654 Evaluation System
General Description
The MAX6654 evaluation system (EV system) consists
of a MAX6654 evaluation kit (EV kit) and a companion
system management bus (SMBus鈩? interface board.
The MAX6654 EV kit is an assembled and tested PC
board that demonstrates the MAX6654 temperature
sensor. It monitors both the junction temperature of the
MAX6654 and the temperature of an external diode-
connected transistor, and converts the temperature to
8-bit or 11-bit (extended resolution mode), 2-wire serial
data. A 2N3906 temperature-sensor transistor comes
soldered to the board in a SOT23 package, but it can
be removed. The board can then be connected through
a twisted pair to a remote diode close to your system.
The Maxim SMBus interface board (MAXSMBUS)
allows an IBM-compatible PC to use its parallel port to
emulate an Intel SMBus 2-wire interface. Windows
廬
95/98/2000-compatible software provides a user-friend-
ly interface to exercise the features of the MAX6654.
The program is menu driven and offers a graphic inter-
face with control buttons and status display.
Order the MAX6654EVSYS for a complete IBM PC-
based evaluation of the MAX6654. Order the
MAX6654EVKIT if you already have an SMBus inter-
face.
Features
o
Measures and Displays Remote Sensor
Temperature
o
Programmable Alarms and Configuration
o
Operating Temperature Ranges
-55擄C to +125擄C (Remote Sensor)
0擄C to +70擄C (Board)
o
SMBus/I
2
C鈩?Compatible Interface
o
Easy-to-Use Menu-Driven Software
o
Assembled and Tested
o
Includes Windows 95/98/2000-Compatible
Software and Demo PC Board
Evaluates: MAX6654
Ordering Information
PART
MAX6654EVKIT
MAX6654EVSYS
SMBus
INTERFACE TYPE
Not included
MAXSMBUS
IC PACKAGE
16 QSOP
16 QSOP
Note:
The MAX6654 EV kit software is provided with the
MAX6654EVKIT. However, the MAXSMBUS board is required to
interface the EV kit to the computer when using the software.
MAX6654EVSYS
Component List
Windows is a registered trademark of Microsoft Corp.
SMBus is a trademark of Intel Corp.
I
2
C is a trademark of Philips Corp.
PART
MAX6654EVKIT
MAXSMBUS
QTY
1
1
DESCRIPTION
MAX6654 EV kit
SMBus interface board
MAX6654EVKIT Component List
DESIGNATION
QTY
DESCRIPTION
0.1碌F, 16V X7R ceramic
capacitor
Taiyo Yuden EMK107BJ104KA
or
Murata GRM39X7R104K016
2200pF, 50V X7R ceramic
capacitor
2 x 10 right-angle female
receptacle
3-pin headers
Not installed
DESIGNATION
QTY
DESCRIPTION
PNP transistor
Central Semiconductor
CMPT3906 or
Fairchild MMBT3906 or
General Semiconductor
MMBT3906 or
On Semiconductor MMBT3906
or
Vishay/Lite-On MMBT3906
Not installed
Slide switch, 0.150in pitch
MAX6654MEE
Shunts
C1
1
Q1
1
C2
J1
JU1, JU2, JU3
JU4, JU5, JU6
1
1
3
0
R1
SW1
U1
None
0
1
1
3
________________________________________________________________
Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim鈥檚 website at www.maxim-ic.com.
