19-2378; Rev 0; 4/02
MAX5915 Evaluation Kit
General Description
The MAX5915 evaluation kit (EV kit) is a fully assembled
and tested surface-mount dual hot-swap controller cir-
cuit board for two PCI 2.2 server line cards. The circuit
uses a MAX5915 IC in a 28-pin TSSOP package. The
EV kit provides independent power control for the
+3.3V, +5V, 鹵12V, and +3.3V auxiliary outputs to the
PCI 2.2 connectors (A/B channels). The EV kit demon-
strates the MAX5915 IC鈥檚 overcurrent shutdown, output
undervoltage monitoring, power-on reset (POR), and
fault-reporting capabilities for channels A and B.
The MAX5915 IC controls the two separate external N-
channel MOSFETs for the +5V and +3.3V outputs,
respectively. The MAX5915 has internal MOSFETs that
control the 鹵12V and +3.3V auxiliary outputs of both
channels. Isolation switches are provided for both
channels鈥?+3.3V and +3.3V auxiliary supplies and to
enable/disable both channels independently.
The EV kit can also be configured to demonstrate a
dual hot-swap design without using the PCI 3.3V/64-bit
and 5V/64-bit PCI connectors.
Features
o
Demonstrates PCI 2.2 Dual Hot-Swap Design
(3.3V/5V PCI Card Designs)
o
Independent Output Controls Provide for Each
Channel
+3.3V and Up to 7.6A (Adjustable)
+5V and Up to 5A (Adjustable)
+12V and Up to 0.5A
-12V and Up to 0.1A
+3.3V AUX and Up to 0.375A
o
Evaluates Hot Swapping 3.3V/64-Bit and 5V/64-Bit
PCI Line Cards
o
Demonstrates Overcurrent Protection with Status
Report
o
Monitors Output Undervoltage for +3.3V, +5V,
鹵12V, and +3.3V AUX with Status Report
o
Independent 3.3V AUX Output with Separate
ON/OFF Control
o
Latched After-Fault Conditions (+3.3V, +5V, 鹵12V)
o
Power-On Reset and Fault Status Reporting
o
Independent On/Off Controls for Channels A/B
o
Surface-Mount Components
o
Fully Assembled and Tested
Evaluates: MAX5915
Ordering Information
PART
MAX5915EVKIT
TEMP RANGE
0擄C to +70擄C
IC PACKAGE
28 TSSOP
Component List
DESIGNATION
C1, C3, C5,
C7, C9
QTY
5
DESCRIPTION
0.1碌F 鹵10%, 16V X7R ceramic
capacitors (0603)
Murata GRM188R71C104KA01
4.7碌F 鹵20%, 16V X5R ceramic
capacitors (1206)
Taiyo Yuden EMK316BJ475ML
47碌F 鹵20%, 16V tantalum
capacitors (C case)
AVX TPSC476M016R0350
470碌F 鹵10%, 6.3V tantalum
capacitors (X case)
Kemet T510X477K006AS
6-pin headers
DESIGNATION
J3
J4
C2, C4, C6,
C8, C10
5
J5鈥揓8
JU1鈥揓U10
N1鈥揘4
QTY
1
1
4
10
4
DESCRIPTION
PCI 5V/64-bit connector
Amp 145166-4
PCI 3.3V/64-bit connector
Amp 145165-4
Uninsulated banana jacks
2-pin headers
30V, 13A N-channel MOSFETs
(8-pin SO)
Fairchild FDS6670A
0.005鈩?鹵1%, 0.25W sense resistors
(1206)
Dale-Vishay WSL1206 0.005鈩?/div>
鹵1%
B43
C11鈥揅16
6
C17鈥揅20
J1, J2
4
2
R1鈥揜4
4
________________________________________________________________
Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim鈥檚 website at www.maxim-ic.com.
