19-2475; Rev 0; 5/02
MAX5427 Evaluation Kit
General Description
The MAX5427 evaluation kit (EV kit) is a fully assembled
and tested surface-mount circuit board that evaluates
the MAX5427 digital potentiometer. Included software
generates the required signals for one-time-programma-
ble operation and allows easy control of the wiper posi-
tion. An on-board 8-pin 碌MAX socket eases replacement
of the device. The EV kit is designed to be connected to
a standard IBM-compatible PC-parallel (printer) port.
Windows
廬
95/98/2000-compatible software provides a
user-friendly interface to exercise the MAX5427鈥檚 fea-
tures. The program is menu driven and offers a graphic
user interface with control buttons. (Note: Windows 2000
requires the installation of a driver; refer to Win2000.pdf
or Win2000.txt located on the diskette for information.)
This EV kit can also be used to evaluate the MAX5428
and MAX5429 digital potentiometers.
Windows is a registered trademark of Microsoft Corp.
Features
o
On-Board 8-Pin 碌MAX Socket
o
Windows 95/98/2000 Evaluation Software
o
Software Adjusts and Programs Wiper Position
o
Fully Assembled and Tested
Evaluates: MAX5427/MAX5428/MAX5429
Ordering Information
PART
MAX5427EVKIT
TEMP RANGE
0擄C to +70擄C
IC PACKAGE
8 碌MAX
Note:
To evaluate the MAX5428 or the MAX5429, request a
free sample of MAX5428EUA or MAX5429EUA with the
MAX5427EVKIT.
Component List
DESIGNATION
C1
QTY
1
DESCRIPTION
4.7碌F 鹵20%, X5R 6.3V
ceramic capacitor (0805)
TDK C2012X5R0J475M
22碌F 鹵20%, X5R 16V ceramic
capacitor (1812)
TDK C4532X7R1C226M
Green surface-mount LED
Dual Shottky diode (SOT23)
Diodes INC BAT54C or
Fairchild BAT54C or
General Semiconductor or
BAT54C
DB-25 right-angle plug (male)
1.6k鈩?鹵5% resistor (1206)
8-pin 碌MAX socket
Wells-CTI 656-1082211
U3
None
None
None
None
1
1
1
1
1
DESIGNATION
QTY
DESCRIPTION
Digital potentiometer
(8-pin 碌MAX)
MAX5427EUA
Low-voltage, analog switch (6-
pin SOT23)
MAX4544EUT
Low-voltage level translator
(10-pin 碌MAX)
MAX1840EUB
MAX5427 PC board
3 1/2in software disk
MAX5427 evaluation kit
MAX5427 data sheet
MAX5427 EV kit data sheet
U1
1
C2
D1
1
1
U2
1
D2
1
J1
R1
U1
1
1
1
